The PicoScope 5000E series combines high-resolution 16-bit technology with fast data acquisition and extensive analysis capabilities. These PC-based oscilloscopes are specifically designed for precision measurement tasks and offer a sampling rate of up to 2.5 GS/s, four analog inputs, and a wide dynamic range of over 73 dB.
The series is ideal for electronics development, embedded systems, automotive applications, power electronics, sensor technology, as well as research and education. Thanks to integrated spectrum analysis, serial protocol decoding, DeepMeasure functions, Math channels, and function and arbitrary waveform generators, both simple and complex measurement tasks can be performed efficiently. The MSO versions further expand the devices with 16 digital inputs.
Differences from other models
The PicoScope 5464E is the most powerful model in the classic 5000E series, offering a bandwidth of 200 MHz at full 16-bit resolution. Compared to the 5462E and 5463E, it has the highest bandwidth and fastest rise time within the standard 5000E series. Compared to the 5000E+ models, the 5464E operates exclusively in 16-bit mode and does not include the additional 8-bit high-speed mode with extended bandwidths up to 500 MHz.
Product features:
- Channels: 4 analog inputs
- Bandwidth: 200 MHz in 16-bit mode
- Vertical resolution: 16 bits
- Extended vertical resolution: Hardware resolution + 4 bits via software
- Maximum sampling rate: 2.5 GS/s for 1 channel, 1.25 GS/s for 2 channels, 625 MS/s for 3 or 4 channels
- Memory: up to 1 GS per channel in 16-bit mode
- Rise time: 1.75 ns
- Selectable bandwidth limits: 20 MHz, 60 MHz, 100 MHz, and 200 MHz
- Input connector: BNC jack
- Input impedance: 50 Ω ±2% or 1 MΩ ±1% || 13 pF ±2 pF
- Input coupling: DC at 50 Ω, AC/DC at 1 MΩ
- Input sensitivity: 1 mV/div to 1 V/div at 50 Ω, 1 mV/div to 4 V/div at 1 MΩ
- Input ranges: up to ±5 V at 50 Ω, up to ±20 V at 1 MΩ
- DC gain accuracy: ±(0.5% of the signal + 1 LSB)
- RMS noise: from 0.022 mV in low voltage ranges
- Time base ranges: 1 ns/div to 5000 s/div
- Time base accuracy: ±2 ppm
- Function generator: Sine, square, triangle, DC, ramps, sinc, Gaussian, and half-sine up to 20 MHz
- Arbitrary waveform generator: 200 MS/s, 32 kS memory, 14-bit vertical resolution
- Trigger functions: Edge, Window, Pulse Width, Dropout, Runt, Interval, and Logic triggers
- Serial protocol decoding for CAN, CAN FD, LIN, SPI, I²C, UART, FlexRay, Ethernet, and many other standards
- FFT spectrum analysis with up to 1 million FFT points
- PC connection: USB 3.0 SuperSpeed via USB-C, USB 2.0 compatible
- Dimensions: 221 × 173 × 30 mm
- Weight: less than 0.7 kg
- Operating temperature: 0 to 40 °C
- Warranty: 5 years
