PICOTEST INJB01 | Feed Bundle 1 - starter package, signal feed network analyzers

Manufacturer number: INJB01

INJB01
INJB01
INJB01
INJB01
INJB01
INJB01
Bundle
Delivery time upon request

€4,570.00

plus VAT. €5,438.30 VAT plus shipping costs

or choose one of the following options:
Request a quote Product is already in cart
Product inquiries Request education-price
Highlights Technical Data Description Related Articles

Picotest INJB01 | Feed Bundle #1: Bundle for network analyzers for signal feed. Consisting of consisting of J2100A, J2101A, J2110A, J2120A, J2130A, J2111B and J2170B power supply.

Technical Data

Description

INJB01 | Feed Bundle 1 - starter package, signal feed network analyzers

Picotest's INJB01 signal injector bundle is a versatile set of test fixtures. They are an essential part of a test setup for qualitative measurements with your network and impedance analyzers. Regardless of whether you need to measure power supplies, regulators or other linear circuits and components, Picotest's signal injectors offer a wide range with low distortion. Also unique in this bundle are the 2 solid state injectors for voltage and current, as well as the line injection adapter for power supply rejection measurements (PSRR, power supply rejection ratio).

This bundle consists of the modules:

  • J2100A feed-in transformer, 1 Hz - 5 MHz
  • J2101A feed-in transformer, 10 Hz - 45 MHz
  • J2110A semiconductor voltage injection, DC - 40 MHz
  • J2120A line voltage injector, 10 Hz - 10 MHz
  • J2130A DC Bias Injector, 10Hz - 10MHz
  • J2111B current injector, DC - 40 MHz incl. J2171A power supply
  • J2170B power supply (High PSRR Power Adapter) (supplied separately)
  • operation manual
