Keysight E36233A | DC power supply, dual output, auto range: 2 x 30 V, 20 A, 400 W, LAN, USB

Name: E36233A | DC power supply, dual output, auto range: 2 x 30 V, 20 A, 400 W, LAN, USB
Brand: Keysight
SKU: E36233A
Price: 3546.0 EUR
Availability: InStock

Manufacturer number: E36233A

1 in stock. Ready to ship in 1 business day

€3,546.00

plus VAT. €4,219.74 VAT plus shipping costs

or choose one of the following options:

Request a quote Product inquiries Request education-price

Keysight E36233A | Autoranging power supply, DC, 400 W, 30 V, 20 A, 2 channel.

Output power: 400 W.
Output voltage: 2 independent output channels 0… 30 V
Output current: 2 independent output channels 0… 20 A
Accuracy voltage: 0.03% of output + 4 mV
Accuracy current: 0.1% + 6 mA
Ripple & Noise (20 Hz to 10 MHz):

Normal Mode Voltage: <350 µVrms / 4.5 mV pp
Normal Mode Current: <1 mA rms

Technical Data

AC input:	100 V - 240 V
Additional functions:	Data logging Output sequencing LIST mode Low current measurement
Article number:	E36233A
Autorange:	Yes
Bidirectional:	No
Dimensions (L x W x H) (mm):	397.8 x 216.5 x 136.2
Interfaces:	USB-TMC, USB-CDC (Virtual COM), LAN optional: GPIB
Model:	E36233A
Number of outputs:	2
Output power (W):	400
Protective devices:	OCP, OVP, OPP
max. Power (A):	20
max. voltage (V):	30

Description

E36233A | DC power supply, dual output, auto range: 2 x 30 V, 20 A, 400 W, LAN, USB

The Keysight E36200 series includes 4 power supplies - 2 models each with 200 W and 400 W. Supply devices with up to 40 A (E36233A) or a voltage of up to 120 V (E36234A) with auto-parallel or auto-series to connect the two outputs internally to a single output with twice the power. Autoranging technology offers the highest available output current at all output voltages.

Note:

When you purchase this new device, you will now receive a "Node-Locked" license for the Keysight measurement and analysis app BenchVue for power supplies BV0003B free of charge . This is limited to the specific device. The license is not limited in time.

On the Keysight website you will find further information on downloading, registering and activating your BenchVue license: To the Keysight website.

Features of the E36200 series:

Usable power 200 W & 400 W

Automatic current regulation at all voltages
Auto-parallel for higher currents up to 40 A.
Auto series for higher voltages up to 120 V.
Variable slew rate to control the inrush current

Low noise, DUT protection and most precise measurements

350 μVrms noise
OV, OC and overheating protection
Local 2-wire or remote 4-wire measurements
Low range current measurement

Fully programmable power supply

USB, LAN, digital I / O and optional GPIB interface
BenchVue PS applications

Advanced features

Data logger
Output LIST
