Keysight EDU36311A | DC power supply, 3 channels: 2x 30 V, 1 A / 6 V, 5 A, 90 W, LAN, USB, Smart Bench Essential

Name: EDU36311A | DC power supply, 3 channels: 2x 30 V, 1 A / 6 V, 5 A, 90 W, LAN, USB, Smart Bench Essential
Brand: Keysight
SKU: EDU36311A
Price: 993.0 EUR
Availability: InStock

Manufacturer number: EDU36311A

Reordered - in stock. Delivery time on request

€993.00

plus VAT. €1,181.67 VAT plus shipping costs

or choose one of the following options:

Request a quote Product inquiries Request education-price

Keysight EDU36311A | DC power supply, table power supply, 3 outputs: 1x 6 V, 5 A, 2x 30 V, 1 A, 90 W, LAN, USB, Smart Bench Triple power supply for industry and training.

Technical Data

AC input:	230 V
Additional functions:	7" display, parallel operation on channel 2 and 3 60V/2A, Smart Bench Essential
Article number:	EDU36311A
Autorange:	No
Bidirectional:	No
Dimensions (L x W x H) (mm):	240.9 x 313.6 x 164.7
Interfaces:	USB, LAN
Model:	EDU36311A
Number of outputs:	3
Output power (W):	90
Protective devices:	OVP, OCP, OTP
Warranty (years):	3
Weight (kg):	9.85
max. Power (A):	5
max. voltage (V):	30

Description

EDU36311A | DC power supply, 3 channels: 2x 30 V, 1 A / 6 V, 5 A, 90 W, LAN, USB, Smart Bench Essential

The robust and intuitive Keysight EDU36311A DC desktop power supply with three outputs (1 x 6 V, 5 A, 2 x 30 V, 1 A) enables precise voltage / power supply at an affordable price. Its 90 W, galvanically separated channels deliver clean and reliable performance.

The 7 inch graphic display (WVGA) gives you a clear overview, from the device settings to the output status. You can easily control the EDU36311A DC power supply remotely via USB or LAN. Keysight's PathWave BenchVue power supply software for the PC is included.

Product features:

Reliable performance

Low output ripple and noise
Excellent programming / readback accuracy
Exceptional grid / load regulation
Superior overvoltage, overcurrent and over temperature protection
Channel 2 and 3: serial or parallel operation for 60 V or 2 A.

Practical benchtop functions

Three independent power supplies in one
Low acoustic noise

Intuitive and easy to use

Special 7 inch color display
Distinctive color-coded channels
Individual regulators for voltage and current
Flexible connection via LAN (LXI) or USB
