LANGER XF1 | Near field probe set XF1, 30 MHz to 6 GHz 4 H field probes, 1 E field probe, cable SMA-SMA

Manufacturer number: XF1

XF1
XF1
XF1
Delivery time upon request

On Request

or choose one of the following options:
Request a quote Product is already in cart
Product downloads Product inquiries Request education-price
Highlights Technical Data Documents / Downloads Description Scope Related Articles

Long XF1 near-field probe set, 30 MHz to 6 GHz.

Technical Data

Documents & Downloads

Datasheet
XF1
pdf | 0.24 MB

Description

XF1 | Near field probe set XF1, 30 MHz to 6 GHz 4 H field probes, 1 E field probe, cable SMA-SMA

The probes from the XF1 set contain electrically shielded measuring heads, which were designed for high-frequency magnetic field measurements on electronic assemblies, components and IC pins.

The passive probes are connected to the 50 ohm input of a spectrum analyzer via cables with SMA connectors and enable comparative magnetic field and current measurements in the frequency range from 30 MHz to 6 GHz.

Near field probe set XF1

  • H-field probe XF-R 400 - 1
  • H-field probe XF-R 3 - 1
  • H-field probe XF-U 2.5 - 1
  • H-field probe XF-B 3 - 1
  • E-field probe XF-E 10
  • SMA-SMA cable
  • Case (240 x 185 x 50) mm
  • quick start Guide

Scope of Delivery:

  • H-field probe XF-R 400 - 1
  • H-field probe XF-R 3 - 1
  • H-field probe XF-U 2.5 - 1
  • H-field probe XF-B 3 - 1
  • E-field probe XF-E 10
  • SMA-SMA cable
  • Case (240 x 185 x 50) mm
  • quick start Guide
