Keysight E4980BL | Precision LCR Meter, Basic Device

Manufacturer number: E4980BL

E4980BL
E4980BL
E4980BL
E4980BL
E4980BL
E4980BL
Reordered - in stock. Delivery time on request

€437.00

plus VAT. €520.03 VAT plus shipping costs

or choose one of the following options:
Request a quote Product is already in cart
Product downloads Product inquiries Request education-price
Highlights Technical Data Documents / Downloads Description Related Articles

Keysight E4980BL | Precision LCR Meter, basic device, test frequency dependent on frequency option.

Technical Data

Documents & Downloads

Datasheet
pdf | 1.55 MB
Userguide
pdf | 4.44 MB
Configuration guide
pdf | 0.76 MB
Datasheet
pdf | 1.55 MB
Userguide
pdf | 4.44 MB
Configuration guide
pdf | 0.76 MB

Description

E4980BL | Precision LCR Meter, Basic Device

The Keysight E4980BL precision LCR component tester combines precise accuracy, speed and versatility for a wide range of applications in research and development (R&D) and manufacturing.

With the E4980BL, the successor to the successful E4980AL, you can determine the relative permeability and relative dielectric constant of a wide variety of materials or measure the key electrical parameters such as resistance, capacitance and inductance on components - with maximum precision in both the high and low impedance range. Corresponding measurement recordings, built-in power supply units that supply the test object with voltage and current, and built-in multimeter functions make work easier and reduce the measurement effort.

The basic device absolutely requires a frequency option. Depending on the option selected, the test frequencies of the LCR meter range from 20 Hz to 300 kHz, 500 kHz or 1 MHz. The E4980B variant has a test frequency of 20 Hz to 2 MHz.

Thanks to the clear display, operation is very simple and intuitive. The versatile LAN, USB and GPIB PC connectivity increases your design and test productivity.

Product features:

  • Frequency: 20 Hz to 300 kHz / 500 kHz / 1 MHz (depending on option), with 4-digit resolution in each range
  • Basic accuracy: 0.05 % basic accuracy with precise measurement repeatability at low and high impedance
  • DC bias: DC bias increase (Keysight option 001)
  • Auto-level control
  • DC resistance
