NI 783610-01 | Analog input module of the C series NI 9231, 10-32 socket, 8 channels, +/- 5 V, 24 bit (51.2 kS / s per channel), IEPE excitation

Manufacturer number: 783610-01

783610-01
Reordered - in stock. Delivery time on request

€5,190.00

plus VAT. €6,176.10 VAT plus shipping costs

or choose one of the following options:
Request a quote Product is already in cart
Product downloads Product inquiries Request education-price
Highlights Technical Data Documents / Downloads Description Related Articles

783610-01 | Analog input module of the C series NI 9231, 10-32 socket, 8 channels, +/- 5 V, 24 bit (51.2 kS / s per channel), IEPE excitation.

Technical Data

Documents & Downloads

Catalog
pdf | 5.05 MB
Brochure
pdf | 2.78 MB
Overview
pdf | 0.25 MB
Datasheet
pdf | 0.16 MB
Configuration guide
pdf | 0.54 MB
Catalog
pdf | 5.05 MB
Brochure
pdf | 2.78 MB
Overview
pdf | 0.25 MB
Datasheet
pdf | 0.16 MB
Configuration guide
pdf | 0.54 MB

Description

783610-01 | Analog input module of the C series NI 9231, 10-32 socket, 8 channels, +/- 5 V, 24 bit (51.2 kS / s per channel), IEPE excitation

The NI-9231 is a high density channel sound and vibration measurement module suitable for measurements with Integrated Electronic Piezoelectric (IEPE) and non-IEPE sensors such as accelerometers, tachometers, and proximity sensors. It enables measurements with a large dynamic range for modern measurement microphones and accelerometers as well as simultaneous sampling. The NI-9231 has a TEDS input path and a 2 mA IEPE excitation source that can be turned on and off, eliminating the need for external sensors and simplifying the data acquisition system.

Product features:

  • Maximum number of differential analog input channels: 8
  • Maximum sampling rate: 51.2 kS / s per channel
  • Voltage measuring range of the analog input: -5 V to 5 V.
  • Isolation of the analog input: none
  • IEPE excitation: 2 mA
  • Connection type front: coaxial type N (qty 8)
  • Protective coating: no
  • With housing: yes
  • Supported hardware platform: CompactDAQ, CompactRIO

Accessoires

960460-03
NI
960460-03
ANSI Compliant Calibration Certificate for NI-9231 (783610-01-ANSI)
Delivery time upon request
€440.00
960460-01
NI
960460-01
Traceable Calibration Certificate for NI-9231 (783610-01-CAL)
Delivery time upon request
€285.00
960460-04
NI
960460-04
ISO 17025 Calibration Certificate for NI-9231 (783610-01-ISO)
Delivery time upon request
€565.00
960680-101
NI
960680-101
Standard Service Program (SSP) for NI-9231 with Traceable Calibration, 3 Years (783610-01-SC3)
Delivery time upon request
€842.70

Alternate products

865665-01
Bundle
Bundle
NI
865665-01
cDAQ-SV1100 bundle 8-channel sound and vibration measurement module NI-9231 including chassis cDAQ-9171
Delivery time upon request
€4,020.00
