NI 865665-01 | cDAQ-SV1100 bundle 8-channel sound and vibration measurement module NI-9231 including chassis cDAQ-9171

Manufacturer number: 865665-01

865665-01
865665-01
865665-01
Delivery time upon request

€4,020.00

plus VAT. €4,783.80 VAT plus shipping costs

or choose one of the following options:
Request a quote Product is already in cart
Product downloads Product inquiries Request education-price
Highlights Technical Data Documents / Downloads Description Related Articles

NI 865665-01 | cDAQ-SV1100 bundle, NI-9231 sound and vibration measurement module, 8 channels, 51.2kS/s, 24 bit, coaxial socket including chassis cDAQ-9171.

  • High-density measurements: Precise detection of sound and vibration signals.
  • Easy integration: Plug-and-play functionality for quick commissioning.
  • Optimal combination: Seamless integration between module and chassis for optimal performance.
  • Flexibly expandable: More than 50 interchangeable I/O modules for versatile customization options.

Technical Data

Documents & Downloads

Catalog
pdf | 5.05 MB
Brochure
pdf | 2.78 MB
Overview
pdf | 3.78 MB
Datasheet
pdf | 0.71 MB

Description

865665-01 | cDAQ-SV1100 bundle 8-channel sound and vibration measurement module NI-9231 including chassis cDAQ-9171

The cDAQ-SV1100 product bundle combines the powerful NI-9231 Sound and Vibration Measurement Module with the versatile cDAQ‑9171 CompactDAQ-USB chassis. This solution provides a reliable and flexible platform for sound and vibration measurement applications, from audio test suites to machine condition monitoring.

NI-9231 Sound and Vibration Measurement Module

The NI-9231 is a high-performance module designed for high-channel density sound and vibration signal acquisition. It supports a wide range of sensors, including IEPE and non-IEPE sensors such as accelerometers, tachometers, and proximity probes. With a wide dynamic range, it is ideal for modern measurement microphones and accelerometers and enables simultaneous measurements. The module features a TEDS input path and a 2 mA IEPE excitation source that can be turned on and off to optimize sensor usage and simplify data acquisition system setup.

NI-9231 features:

  • Up to 8 differential analog input channels
  • Maximum sample rate of 51.2 kS/s per channel
  • Analog input measurement range: -5 V to 5 V
  • Front connector type: Coaxial Type N (8 connectors)
  • No analog input isolation
  • No conformal coating
  • Enclosed
  • Compatible with CompactDAQ and CompactRIO

CompactDAQ USB Chassis cDAQ‑9171

The cDAQ‑9171 is a rugged and portable CompactDAQ USB chassis that enables seamless integration of USB-enabled sensors and electrical measurements. It accommodates a variety of hot-swappable C-Series I/O modules and features four integrated 32-bit counter/timers for additional functionality. The chassis offers simple plug-and-play functionality and controls timing, synchronization, and data transfer between the modules and the host computer.

Additional features of the cDAQ‑9171:

  • Continuous waveform measurements thanks to patented NI streaming technology
  • Simple and fast measurements with the NI-DAQmx driver software and automatic code generation with the DAQ Assistant
  • Bus-powered for high mobility
  • Screw-on USB cable for additional security and strain relief
  • Includes NI-DAQmx driver software

Accessoires

786657-01
NI
786657-01
Cable, 10-32 coaxial plug to BNC socket, 50 ohms, 0.9 m
32 in stock. Ready to ship in 1 business day
€33.00
786659-01
NI
786659-01
Cable, 10-32 coaxial plug to 10-32 coaxial plug, 50 ohms, 3 m
Delivery time upon request
€45.00
785748-3501
NI
785748-3501
FlexLogger, subscription license, download
Delivery time upon request
€575.00
788509-35
NI
788509-35
LabVIEW+ Suite, Subscription License, Download
Delivery time upon request
€4,530.00
781866-35
NI
781866-35
LabVIEW, License for Target Systems and Debugging
Ready to ship in 5 to 10 business days
€2,940.00

Alternate products

783610-01
NI
783610-01
Analog input module of the C series NI 9231, 10-32 socket, 8 channels, +/- 5 V, 24 bit (51.2 kS / s per channel), IEPE excitation
18 in stock. Ready to ship in 1 business day
€5,190.00
781425-01
NI
781425-01
cDAQ-9171, CompactDAQ chassis (USB, 1 slot)
5 in stock. Ready to ship in 1 business day
€540.00
