Keysight RP5913A | Regenerative DC power supply unit, 80 V, +/-40 A, 2 kW, 200/520 VAC, LAN, USB, CAN IO

Name: RP5913A | Regenerative DC power supply unit, 80 V, +/-40 A, 2 kW, 200/520 VAC, LAN, USB, CAN IO
Brand: Keysight
SKU: RP5913A
Price: 5187.0 EUR
Availability: InStock

Manufacturer number: RP5913A

Delivery time upon request

€5,187.00

plus VAT. €6,172.53 VAT plus shipping costs

or choose one of the following options:

Request a quote Product inquiries

Keysight RP5913A | Regenerative DC power supply unit, 80 V, +/-40 A, 2 kW, 200/520 VAC, LAN, USB, CAN IO.

Technical Data

AC input:	110 V - 520 V, 3P, 50 Hz / 60 Hz
Additional functions:	Integrated electronic load, Built-in voltage and current measurement
Article number:	RP5913A
Autorange:	Yes
Bidirectional:	Yes
Dimensions (L x W x H) (mm):	800.21 x 464 x 88.4
Interfaces:	LAN, USB Optional: GPIB
Model:	RP5913A
Output power (W):	2,000
Power factor:	0,99
Protective devices:	OVP, OCP, OPP
Weight (kg):	12
max. Power (A):	40
max. voltage (V):	80

Description

RP5913A | Regenerative DC power supply unit, 80 V, +/-40 A, 2 kW, 200/520 VAC, LAN, USB, CAN IO

The RP5900 series is a powerful family of bidirectional DC power supplies with regenerative function. It combines high output power, flexible control and efficiency in a compact size. The devices offer an output of 2 kW to 12 kW per unit and can be connected in parallel to form systems with up to 96 kW. They support voltages up to 800 V and currents up to 240 A.

Thanks to their regenerative technology, the devices can feed energy back into the grid with low losses during inverter operation. Thanks to precise control, an integrated arbitrary generator and extensive communication interfaces (USB, LAN, GPIB, CAN, RS232, analog I/O, WebGUI), the series is ideal for test benches, laboratories and automated test systems (ATE).

Typical areas of application

The RP5900 series is used in research, development and production - particularly in the following areas:

Electromobility (battery, BMS and charger testing)
Power electronics and DC/DC converter testing
Motor control and drive testing
Inverter and photovoltaic testing
ATE systems and automated end-of-line testing
