Keysight MP4301A | Modular Solar Array Simulator Mainframe, SAS, 6kW, 200/208Vac

Manufacturer number: MP4301A

MP4301A
MP4301A
MP4301A
MP4301A
MP4301A
MP4301A
MP4301A
MP4301A
MP4301A
Delivery time upon request

On Request

or choose one of the following options:
Request a quote Product is already in cart
Product downloads Product inquiries Request education-price
Highlights Technical Data Documents / Downloads Description Related Articles

Keysight MP4301A | Modular Solar Array Simulator Mainframe for 6 modules, 6 kW, 200/208 Vac.

Technical Data

Documents & Downloads

Datasheet
pdf | 0.97 MB
Configuration guide
pdf | 3.67 MB

Description

MP4301A | Modular Solar Array Simulator Mainframe, SAS, 6kW, 200/208Vac

The Keysight MP4301A is a 6kW, 200/208 Vac mainframe with excellent power and channel density. The 2U mainframe can accommodate up to six SAS modules and thus offers a compact solution even when emulating many PV segments.

Primarily a programmable DC power source with very low output capacitance, the Keysight MP4301A Modular Solar Array Simulator (SAS) is capable of rapidly determining the IV curve of various arrays under various conditions (e.g. temperature, age, etc.). simulate.

The Keysight SAS offers three modes of operation: simulator (SAS), table and fixed mode. To accurately simulate the IV curve of a solar array, use SAS or Table mode. When a standard power supply is required as a source or load, use Fixed Mode.

The MP4301A is part of the Keysight MP4300 series, which offers two classes of 1kW SAS modules: the powerful MP4361A 160V/10A auto-ranging module and the MP4362A 130V/8A module.

Deploy and debug new test systems quickly thanks to the 5-inch touchscreen and intuitive graphical user interface (GUI).

Product features:

  • Precise simulation of any type of solar system
  • 6kW mainframe with 200/208 VAC
  • Up to 6 slots for SAS modules
  • Compact size: 2U mainframe
  • Two classes of 1kW SAS modules: MP4361A 160V/10A auto-ranging module and MP4362A 130V/8A module
  • Intuitive 5" touchscreen interface
  • Fast IV curve switching and fast recovery switching time
  • Simple simulation of environmental conditions

Accessoires

MP4361A
Keysight
MP4361A
Solar Array Simulator Auto Ranging Module 160V 10A 1KW for SAS MP4301A/MP4302A
Delivery time upon request
On Request
MP4362A
Keysight
MP4362A
Solar Array Simulator Module, 0-130 V, 0-8 A, 1 kW
Delivery time upon request
€6,309.00
