B&K Precision 9805 | Power Supply Unit, AC, Programmable, 1500VA / USB, RS-232, LAN, GPIB, 9800 Series

Name: 9805 | Power Supply Unit, AC, Programmable, 1500VA / USB, RS-232, LAN, GPIB, 9800 Series
Brand: B&K Precision
SKU: BK9805
Price: 6390.0 EUR
Availability: InStock

Manufacturer number: BK9805

Delivery time upon request

€6,390.00

plus VAT. €7,604.10 VAT plus shipping costs

or choose one of the following options:

Request a quote Product inquiries Request education-price

B&K Precision 9805 | Power supply unit, AC, programmable, 1500VA / USB, RS-232, LAN, GPIB.

Technical Data

AC input:	1P
AC output:	1P
Article number:	BK9805
DC output reversible:	AC Source
Dimensions (L x W x H) (mm):	535.7 x 439 x 131.4
Frequency range:	45 Hz - 500 Hz
Grid simulation:	Yes
Interfaces:	USB, GPIB, LAN, RS-232
Mains feedback:	No
Measurement functions:	Vrms, Irms, Ipeak, Frequency, Power Factor (PF), Apparent Power, Active Power, Elapse Time
Model:	BK9805
Output power (W):	1,500
PLD Testfunction:	Yes
Power factor:	0,7
Protective devices:	OVP, OCP, OPP, OTP
Warranty (years):	2
Weight (kg):	52.16
max. Power (A):	12
max. voltage (V):	300

Documents & Downloads

Datasheet

pdf | 2.55 MB

Description

9805 | Power Supply Unit, AC, Programmable, 1500VA / USB, RS-232, LAN, GPIB, 9800 Series

The B&K Precision 9805 is a high-performance AC power source with 1500 VA and an integrated GPIB interface for easy integration into automated test systems. It is particularly suitable for demanding applications in power electronics, grid simulation environments, pre-compliance tests as well as for the

With extensive functions such as List Mode, Power Line Disturbance (PLD), Dimmer Simulation and Voltage/Frequency Sweeps, the device enables realistic simulation of grid conditions and transient faults. Communication can take place via USB, RS232, LAN or even GPIB - ideal for professional test benches.

Product features:

Output power: up to 1500 VA
Output voltage: 0 to 300 V, with 0.1 V resolution
Frequency range: 45 Hz to 500 Hz
Max. Output current (RMS): 12 A at 150 V, 6 A at 300 V
Max. Output current (peak): 36 A at 150 V, 18 A at 300 V
Phase angle adjustment: 0° to 360°, resolution 0.1°
Modes: PLD, sweep, dimmer, list mode with up to 100 steps
Communication: USB, RS232, LAN and GPIB (integrated as standard)
Measurement functions: Voltage, current (RMS/peak), power, frequency, PF
Dimensions: 439 x 131.4 x 535.7 mm
Weight: 52.16 kg

The 9805 is the top version of the series with maximum performance and integrated GPIB interface as standard. It offers identical performance data to the 9805B, but is particularly suitable for environments with existing GPIB-based measurement systems. In contrast to the 9801 (300 VA) and 9803B (750 VA), the full power of 1500 VA is available here with an extended communication range. Ideal for professional users with high demands on performance and connectivity.
