OMICRON Lab Bode 500 | Vector Network & Impedance Analyzer, 10 mHz to 450 MHz, integrated Gain/Phase Meter

Name: Bode 500 | Vector Network & Impedance Analyzer, 10 mHz to 450 MHz, integrated Gain/Phase Meter
Brand: OMICRON Lab
SKU: BODE500
Price: 13900.0 EUR
Availability: InStock

Manufacturer number: BODE500

2 in stock. Ready to ship in 1 business day

€13,900.00

plus VAT. €16,541.00 VAT plus shipping costs

or choose one of the following options:

Request a quote Product inquiries Request education-price

OMICRON Lab Bode500 | Vector network analyzer, gain/phase meter and impedance analyzer from 10 mHz to 450 MHz.

Signal Source:
- Frequency Range: 10 mHz to 450 MHz
- Output Level: -50 dBm to 16 dBm
- Connector: N-type female
Measurement Channels
- Input Impedance 50 Ω - 1 MΩ / 25 pF (also adjustable via software)
- Receiver Bandwidth Selectable from 1 Hz to 15 kHz
- Input Attenuator Adjustable 0 dB to 20 dB
- Input Sensitivity 1 Vrms (at 0 dB input attenuator)
- Dynamic Range: > 120 dB
- Connector: N-type female
Other:
- Rear USB Port
- Rear Port for External Power supply
- Dimensions: W 260 x H 50 x D 275 mm
- Weight: 2.2 kg

Technical Data

Warranty (years):	2
Weight (kg):	2.2

Description

Bode 500 | Vector Network & Impedance Analyzer, 10 mHz to 450 MHz, integrated Gain/Phase Meter

The PC-controlled Bode500 vector network analyzer is the ideal solution for measuring transfer functions and impedances in the frequency range of 10 mHz to 450 MHz, thus enabling efficient and cost-effective testing of electronic components and circuits. With the OMICRON Lab Bode 500 vector network analyzer and the included "Bode Analyzer Suite" PC software, the Bode 500 network analyzer can not only determine S-parameters but also be used to measure transfer functions and perform frequency analysis of complex impedances such as capacitances and inductances. Due to its excellent price-performance ratio, the Bode 500 network analyzer is ideally suited for industrial applications in production, research, and development. Furthermore, the "Bode Analyser Suite" offers many useful functions for education and research in academic and university settings. With the Bode500, you have three instruments in one: Vector Network Analyzer, Gain/Phase Meter (Frequency Response Analyzer), Impedance Analyzer. The Vector Network Analyzer function allows you to easily measure: S-parameters in a 50-ohm system: S11 (input reflection) and S21 (forward transmission/gain/attenuation of the input signal), reflection coefficient and return loss, and insertion loss. Filtering

Group delay

Transmission characteristics of amplifiers

The gain/phase meter function allows the measurement of:

Transmission function of electronic circuits
Stability of power supplies and control loops (such as DC/DC converters)
Power Supply Rejection Ratio (PSRR) or the supply voltage rejection in power supplies

As an impedance analyzer, the Bode 500 allows you to analyze:

Electromagnetic components such as transformers and chokes
Capacitors and their parasitic effects Properties
Ultrasonic and piezoelectric components or systems
High-quality circuits such as quartz filters and oscillators
Input and output impedance of electronic circuits

Scope of Delivery:

Bode 500 Vector Network Analyzer
Bode Analyzer Suite
Bode 500 Quick Start Guide
Universal power supply with 100...240 V (47...63 Hz), +10...24 V / 10 W
USB cable
1 x N thru adapter (f - f)
1 x N short adapter (m)
1 x N 50 Ω Load (m)
2 x N-N cable 50 cm (m - m)
2 x N-BNC adapter (m - f)
1 x BNC T-adapter (f - f - f)
3 x N-BNC cable 50 cm (m - m)

Accessoires
