NI 784781-01 | PXIe-1092, PXI Express chassis, 3U, 9 slots

Manufacturer number: 784781-01

784781-01
784781-01
784781-01
1 in stock. Ready to ship in 1 business day

€8,170.00

plus VAT. €9,722.30 VAT plus shipping costs

or choose one of the following options:
Request a quote Product is already in cart
Product downloads Product inquiries Request education-price
Highlights Technical Data Documents / Downloads Description Related Articles

784781-01 | PXIe-1092, PXI Express chassis, 3U, 9 slots.

Technical Data

Documents & Downloads

Catalog
pdf | 2.54 MB
Brochure
pdf | 1.04 MB
Overview
pdf | 1.35 MB
Configuration guide
pdf | 1.88 MB

Description

784781-01 | PXIe-1092, PXI Express chassis, 3U, 9 slots

The PXIe-1092 features a high bandwidth backplane and up to 82W of power and cooling in each slot to meet the needs of demanding test and measurement applications. The full hybrid backplane offers outstanding flexibility for the arrangement of measurement modules, as it accepts PXI Express modules in each slot as well as PXI hybrid compatible modules in up to seven slots. The chassis also offers an option for timing and synchronization in the form of an integrated temperature-controlled crystal oscillator (OCXO), which increases the clock accuracy and enables the routing of external clocks and triggers. The chassis includes a peripheral expansion slot on slot 10 to provide power for modules that occupy multiple slots.

Product features:

  • PXI chassis type: PXIe
  • Number of slots: 10
  • Maximum system bandwidth: 24 GB / s
  • Chassis power supply: AC
  • Cooling capacity at the slot: 82 W.
  • Integrated clock: VCXO
  • External clocking: No.
  • Number of PXI Express slots: 1
  • Number of hybrid slots: 7
  • Number of PXI slots: 0
  • System time control slot: Yes
  • External trigger access: No.
  • Redundant hardware: No.

Accessoires

Accessoires

960457-01
NI
960457-01
Traceable Calibration Certificate for PXIe-1092 (786991-01-CAL)
Delivery time upon request
€440.00
960680-101
NI
960680-101
Standard Service Program (SSP) for PXIe-1092 with Traceable Calibration, 3 Years (786991-01-SC3)
Delivery time upon request
€2,077.60
960457-04
NI
960457-04
ISO 17025 Calibration Certificate for PXIe-1092 (786991-01-ISO)
Delivery time upon request
€875.00
960457-03
NI
960457-03
ANSI Compliant Calibration Certificate for PXIe-1092 (786991-01-ANSI)
Delivery time upon request
€670.00
