NI 781475-01 | PXIe-6376, multifunction I / O module with 3.5 MS / s per channel (8 simultaneous AI, 24 DIO, 2 AO)

Name: 781475-01 | PXIe-6376, multifunction I / O module with 3.5 MS / s per channel (8 simultaneous AI, 24 DIO, 2 AO)
Brand: NI
SKU: 781475-01
Price: 10700.0 EUR
Availability: OutOfStock

Manufacturer number: 781475-01

Delivery time upon request

€10,700.00

plus VAT. €12,733.00 VAT plus shipping costs

You would like to request an offer? Please add items to the shopping cart and request an offer there.

781475-01 | PXIe-6376, multifunctional I / O module with 3.5 MS / s per channel (8 simultaneous AI, 24 DIO, 2 AO).

Independant Consulting

More than 50 strong brands and exclusive partnerships.

About the brands

Services

More than instruments: Before, during and after sales.

Go to the services

Demonstration & Consulting

Sales and technical support close to you.

Start request

Technical Data

Absolute accuracy of the AI (microV):	2688
Bustype:	PXI Express
Connection type front:	68-Pin, Weiblich VHDCI
Max. Number of differential analogue input channels:	8
Max. Number of ground-related analogue input channels:	0
Max. Update rate (MS/s):	3.3
Measured electrical signal:	Voltage
Measurements per second/sampling rate (MS/s):	3.57
Module width:	1
Number of analogue output channels:	2
Number of bidirectional digital channels:	24
Number of counters/timers:	4
Number of digital inputs:	0
Number of digital outputs:	0
Protectively coated:	Nein
Resolution of the analogue input:	16 bit
Samplerate:	3.57 MS/s pro Kanal
Simultaneous scanning:	Ja
Voltage measuring range of the analogue input (V):	-5 V bis 5 V, -2 V bis 2 V, -10 V bis 10 V, -1 V bis 1 V
With case:	Ja

Documents & Downloads

Brochure

pdf | 0.89 MB

Detaildescription

781475-01 | PXIe-6376, multifunction I / O module with 3.5 MS / s per channel (8 simultaneous AI, 24 DIO, 2 AO)

The PXIe ‑ 6376 is a multifunction data acquisition module with simultaneous sampling. It offers analog and digital I / O, four counters with 32 bit resolution and digital triggering. The NI ‑ STC3 timing and synchronization technology enables advanced timing functions, including independent analog and digital timing engines and repeatable triggering of measurement tasks. The PXIe ‑ 6376 is suitable for a wide variety of applications including IF digitization, transient signal recording, ISDN, ADSL, and POTS telecommunications manufacturing testing, ultrasonic and sonar testing, and high energy physics. The NI ‑ DAQmx driver with configuration program included in the scope of delivery simplifies the configuration and the execution of measurements.

Product features:

Bus type: PXIe
Maximum number of ground-related analog input channels: 0
Maximum number of differential analog input channels: 8
Simultaneous sampling: Yes
Maximum sampling rate: 3.57 MS / s per channel
Resolution analog input: 16 bit
Absolute accuracy of analog input: 2688 μV
Number of analog output channels: 2
Maximum update rate: 3.3 MS / s per channel
Number of bidirectional digital channels: 24
Direction of current flow: -
Number of counters / timers: 4
Measured electrical signal: voltage
Analog input FIFO buffer size: 8182 samples
