The Gossen Metrawatt M275X is the most powerful variant in the METRACAL CM series and is designed for users who require maximum flexibility and versatility in process calibration. As a combination of multimeter and advanced process calibrator, the device enables the precise measurement and simulation of a wide range of electrical and physical quantities and is ideally suited for demanding calibration, testing, and commissioning tasks. In addition to classic measurement and calibration functions for voltage, current, resistance, frequency, and temperature, the M275X offers an extended range of functions for complex applications. These include flexible signal waveforms such as ramp and interval functions, extensive storage and documentation capabilities, and convenient data transfer. Dual operation allows measurement and simulation tasks to be performed simultaneously, enabling the efficient verification of complete measurement chains. The robust design, high measurement accuracy, and extensive configuration options make the M275X the optimal solution for use in industry, test fields, and calibration laboratories. It is particularly suitable for users who require maximum control, documentation, and automation in their calibration processes.
Product Features:
- Multimeter and advanced process calibrator for professional applications
- Model: METRACAL CM (High-end variant), Item number M275X
- Dual mode for simultaneous measurement and simulation
- Measurement functions: V, mA, mA Loop, Ω, TempTC, TempRTD, Hz, CPM
- Calibration functions: V, mA (source), mA (sink), Ω, TempTC, TempRTD, Hz, CPM
- Support for 2-, 3-, and 4-wire resistance and RTD measurements
- Wide selection of supported RTD types (e.g., Pt100, Pt1000, Ni100, Ni1000)
- Support for numerous thermocouple types (e.g., K, J, T, N, R, S, B, E)
- DC voltage measurement up to approx. ±31 V
- DC current measurement up to approx. ±26 mA
- Resistance measurement up to approx. 4.1 kΩ
- Frequency and pulse generator (Hz and CPM)
- Extended calibration modes: Manual, Ramp, Interval, Table function
- Individually storable test and calibration profiles
- Integrated data logger with large memory for extensive measurement series
- Internal real-time clock with timestamp for Documentation purposes
- Wireless communication (e.g., Bluetooth) for data transfer
- USB interface (optional via accessories)
- High-resolution 3.5-inch TFT color display
- Digital display combined with analog bargraph
- High measurement resolution and fast measurement rate
- Rechargeable LiPo battery with long operating time
- Robust, industrial-grade housing
- IP52 protection rating
- Compact design for mobile use
- Suitable for calibration laboratories, industry, and demanding service applications
