Gossen Metrawatt METRISO PRIME high-voltage insulation measuring device with battery operation

Name: METRISO PRIME high-voltage insulation measuring device with battery operation
Brand: Gossen Metrawatt
SKU: M550T
Price: 1625.0 EUR
Availability: OutOfStock

Manufacturer number: M550T

Gossen Metrawatt METRISO PRIME high-voltage insulation measuring device with battery operation

Ready to ship in 5 to 10 business days

€1,625.00

plus VAT. €1,933.75 VAT plus shipping costs

You would like to request an offer? Please add items to the shopping cart and request an offer there.

Request educational price

Gossen METRISO PRIME M550T high voltage insulation tester; battery powered.

Analog high-voltage insulation measuring device with measuring voltages: 100, 250, 500, 1000 V (according to EN 61 557 part 1) and 1500, 2000, 2500, 5000 V
Wide measuring range from 10 k ... 1 T ohm
Very clear logarithmic display
Measuring voltages 100, 250, 500, 1000, 1500, 2000, 2500, 5000 V
Measurements up to 1000 V according to DIN VDE 0413
Measuring range 100 k ... 100 M ohm (1000 V)
Voltage measurement up to 2000 V DC, AC
Guard connection eliminates surface currents
By replacing the battery insert with the crank inductor, the battery-operated METRISO PRIME becomes a hand-operated device

Independant Consulting

More than 50 strong brands and exclusive partnerships.

About the brands

Services

More than instruments: Before, during and after sales.

Go to the services

Demonstration & Consulting

Sales and technical support close to you.

Start request

Detaildescription

METRISO PRIME high-voltage insulation measuring device with battery operation

Analog insulation measuring device 5000 volts, 0.4 MOhm to 1 TOhm.

Lieferumfang

METRISO PRIME (battery operated):

1 high-voltage insulation measuring device with permanently connected test leads and test probes,
2 alligator clips (5 kV version)
Battery drawer including batteries
1 shoulder strap
1 instruction manual
