Fluke 87V-MAX / E2-KIT | Combokit Fluke 87V MAX E2 for industrial electricians
- True RMS values of AC voltage and current for precise measurements on non-linear signals
- Measurement of direct and alternating voltages up to 1000 V.
- Measurements up to 10 A (20 A for 30 seconds)
- Frequency up to 200 kHz
- With the built-in thermometer, you can conveniently record the temperature values without having to carry a separate measuring device.
- Min./Max./ mean value recording plus 250 μs peak Min./Max. To automatically record deviations
- Unique function for precise voltage and frequency measurements on motor drives with variable frequency (VFD) and other electrical devices in which harmonics overlap the fundamental frequency
- Large display and two-level bright backlighting as well as backlit keys for improved readability
- High-resolution display mode with a display range of 19,999
- Long battery life (800 hours)
Technical Data
Analogue segment display: | Ja |
---|---|
Article number: | 5160712 |
Backlight: | Ja |
Basic precision: | AC 0,7% / DC 0,05% |
Capacity measuring range: | 0,01nF - 9999µF |
Current measuring range AC/DC: | 0,1µA - 10A / 0,1µA - 10A |
Data memory / logger: | Nein / Nein |
Dimensions (L x W x H) (mm): | 215 x 101 x 60 |
Diode test / continuity test: | Ja / Ja |
Display Hold / Auto-Hold: | Ja / Ja |
Display resolution: | 20000 |
Electrical safety: | CAT III 1000V, CAT IV 600V |
Frequency measuring range: | 0,5Hz - 199,99kHz |
Interfaces: | Keine |
Min. / Max. Recording: | Ja / Ja |
Model: | FLUKE-87V-MAX/E2 KIT |
Number of positions: | 4.5 |
Resistance measuring range: | 0,1Ω - 50MΩ |
Temperature measurement ( PT100 / Type K / Type J): | -200°C - +1090°C |
True effective measurement TRMS: | Ja |
Voltage measuring range AC/DC: | 0,1mV - 1000V / 0,1mV - 1000V |
Warranty (years): | 30 |
Weight (kg): | 0.6985 |
Detaildescription
87V-MAX / E2-KIT | Combokit Fluke 87V MAX E2 for industrial electricians
The 87V MAX has all the proven features of today's most popular digital multimeter, the Fluke 87V, and much more.
Fluke's most robust digital multimeter. The 87V MAX has an industrial housing and a removable holster. The holster can also be used as a measuring tip holder for one-handed operation.
Degree of protection IP67
Fully waterproof and dustproof so you can work reliably in all conditions.
Withstands heat and cold
The meter has an extended operating temperature range from -40 ° C (up to 20 minutes) to +55 ° C.
Lieferumfang
- L224 silicone test leads
- AC220 alligator clips
- TP238 test probes
- Magnetic straps
- 80BK temperature sensor
- Holster
- Bag C35
- battery
- Operation manual.
