LANGER RF BASIC SET | Near-Field Probes 30 MHz to 3 GHz for EMC Diagnostics

Manufacturer number: RF BASIC SET

RF BASIC SET
Delivery time upon request

€1,685.10

plus VAT. €2,005.27 VAT plus shipping costs

or choose one of the following options:
Request a quote Product is already in cart
Product inquiries Request education-price Share
Highlights Description Related Articles

Long RF BASIC SET | Near-Field Probes 30 MHz to 3 GHz for EMC Diagnostics.

Description

RF BASIC SET | Near-Field Probes 30 MHz to 3 GHz for EMC Diagnostics

The RF Basic Set from Langer EMV-Technik GmbH is a professional near-field probe set for development-accompanying EMC diagnostics. It is ideal for engineers, developers and test technicians who want to quickly and reliably detect, analyze and reduce electromagnetic interference in electronic assemblies.

Optimal solution for EMC measurement and localization of RF interference sources

With six passive near-field probes for electric and magnetic fields, the RF Basic Set offers a precise and flexible way to analyse HF interference sources on printed circuit boards (PCBs). The frequency range from 30 MHz to 3 GHz covers the majority of typical EMC problems and makes the set an indispensable tool for early EMC optimization in electronics development.

Typical areas of application:

  • Locating RF interference sources on printed circuit boards (PCB)
  • Measuring electric and magnetic near fields
  • Indirect high-frequency current measurement on lines or IC pins
  • Integration into automated near-field scanning systems
  • Compatible with spectrum analyzers, measurement receivers and oscilloscopes

Included in the RF Basic Set:

  • 1× RF-R 400-1 - H-field probe (30 MHz - 3 GHz)
  • 1× RF-R 3-2 - H-field probe (30 MHz - 3 GHz)
  • 1× RF-B 3-2 - H-field probe (30 MHz - 3 GHz)
  • 1× RF-U 2.5-2 - H-field probe (30 MHz - 3 GHz)
  • 1× RF-E 02 - E-field probe (30 MHz - 1,5 GHz)
  • 1× RF-E 05 - E-field probe (30 MHz - 3 GHz)
  • 1× SMB-BNC measuring cable (1 m)
  • 1× Case 5 system case for up to 5 near-field probes

Product features:

  • Frequency range: 30 MHz - 3 GHz
  • Types: H-field and E-field near-field probes
  • Measurement output: 50 Ohm, suitable for standard measuring devices
  • Recommended addition: external preamplifier
  • Connection: SMB-BNC measurement cable (1 m)

Alternate products (6 products)

Alternate products (6 products)

RF-R 400-1
LANGER
RF-R 400-1
H-field probe 30 MHz to 3 GHz, SMB(m) connection
Delivery time upon request
€279.40
RF-R 3-2
LANGER
RF-R 3-2
H-field probe 30 MHz to 3 GHz
Delivery time upon request
€317.90
RF-B 3-2
LANGER
RF-B 3-2
H-field probe 30 MHz to 3 GHz
Delivery time upon request
€304.70
RF-U 2.5-2
LANGER
RF-U 2.5-2
H-field probe 30 MHz to 3 GHz
Delivery time upon request
€292.60
RF-E 02
LANGER
RF-E 02
E-field probe, 30 MHz to 1.5 GHz
Delivery time upon request
€327.80
RF-E 05
LANGER
RF-E 05
E-field probe 30 MHz to 3 GHz
Delivery time upon request
€327.80

About the Manufacturer

LANGER
LANGER
Langer EMV Technik was founded in 1998. The company is one of the top specialists in the field of electromagnetic compatibility (EMC).
