Keysight U2021XA | USB broadband power sensor, 50 MHz to 18 GHz, X series

Manufacturer number: U2021XA

Keysight U2021XA
Keysight U2021XA
Keysight U2021XA
Keysight U2021XA
Keysight U2021XA
Keysight U2021XA
Keysight U2021XA
Keysight U2021XA
Keysight U2021XA
Keysight U2021XA

Delivery time upon request

On Request

You would like to request an offer? Please add items to the shopping cart and request an offer there.
Highlights Documents & Downloads Description Related Articles

Keysight U2021XA | Power sensor 50 MHz to 18 GHz. Measure peak and average power directly on the PC.

  • Frequency range from 50 MHz to 18 GHz
  • Wide dynamic range from -30 to +20 dBm (peak / limited); -35 to +20 dBm (average)
  • 30 MHz video bandwidth
  • Single measurement in real time mode with 80 MSa / s
  • Internal calibration and resetting to "zero" by means of a built-in reference DC voltage source and switching element, so that calibration is possible even though the sensor is supplied with a signal to be measured. A connection to your DUT is therefore unnecessary for calibration
  • High measuring speed of> 3500 measurements / second (free running / fast buffer mode)
  • Available measurement processes for: DME, GSM, EDGE, CDMA, WCDMA, WLAN, WiMAX and LTE
  • Connection directly to the PC via USB; no other power meter or power supply is needed
  • Warranty: 3 years

Areas of application:

  • development
  • production
  • General radio frequency technology
  • Mobile radio technology
  • Aviation and defense technology
  • Radar technology

Another power sensor:

  • U2022XA with bandwidth 50 MHz to 40 GHz with similar properties

Independant Consulting

More than 50 strong brands and exclusive partnerships.

About the brands

Services

More than instruments: Before, during and after sales.

Go to the services

Demonstration & Consulting

Sales and technical support close to you.

Start request

Documents & Downloads

Brochure
pdf | 1.89 MB
Datasheet
pdf | 0.91 MB

Detaildescription

U2021XA | USB broadband power sensor, 50 MHz to 18 GHz, X series

The U2021XA power sensor from Keysight (formerly Agilent's electronic measurement technology), with which both the peak power and the average power of signals in the frequency range from 50 MHz to 18 GHz can be measured, is characterized by the fact that it is directly connected to your PC via the USB interface can be connected. BenchVue software (30 days trial version) is supplied free of charge with the power sensor, which you install on your PC and you already have a complete measuring unit to measure the power level of the high-frequency signals.

For triggering on very narrow and small signals that hardly stand out from the noise level, the power sensors also have trigger inputs and trigger outputs, so that exactly these signals can be triggered. This is made possible by a connection with a BNC or SMB connector from the signal source or the DUT (device under test) directly to the trigger input of the power sensor.

Note:

When you purchase this new device, you will now receive a "Node-Locked" license for the Keysight measurement and analysis app BenchVue for power meters BV0007B free of charge . This is limited to the specific device. The license is not limited in time.

On the Keysight website you will find further information on downloading, registering and activating your BenchVue license: To the Keysight website.
