Keysight HD300PWRA | Power Application Software for InfiniiVision Oscilloscopes HD3 Series

Manufacturer number: HD300PWRA

HD300PWRA
HD300PWRA
HD300PWRA
HD300PWRA
HD300PWRA
HD300PWRA
Ready to ship in 5 to 10 business days

€1,914.00

plus VAT. €2,277.66 VAT plus shipping costs

or choose one of the following options:
Request a quote Product is already in cart
Product downloads Product inquiries Request education-price
Highlights Documents / Downloads Description Related Articles

Keysight HD300PWRA | Power Application Software for InfiniiVision HD3 Series Oscilloscopes.

Documents & Downloads

Overview
pdf | 0.27 MB
Userguide
pdf | 3.01 MB

Description

HD300PWRA | Power Application Software for InfiniiVision Oscilloscopes HD3 Series

The power software package for Keysight's InfiniiVision HD3 Series oscilloscopes enables a wide range of automated power supply characterization measurements, including critical frequency response measurements such as power supply rejection ratio (PSRR) and control loop response.

  • Input measurements
    • Power quality: active power, apparent power, reactive power, power factor, crest factor (V and I), phase angle
    • Current harmonics (based on IEC 61000-3-2 up to the 40th harmonic)
    • Power quality: active power, apparent power, reactive power, power factor, crest factor (V and I), phase angle. Harmonics)
    • Inrush current
  • Switching measurements
    • Rds-on and Vce-sat
    • Switching losses (power and energy)
    • Rise speed (dv/dt and di/dt)
    • Modulation (duty cycle, pulse width, period, frequency, etc..., over time)
  • Measurements at the output
    • Output ripple
    • On time/Off time
    • Swing-in time
    • Resonant efficiency
  • Frequency response measurements
    • Power supply rejection ratio (PSRR) - Bode
    • Control loop response - Bode
