FLUKE Networks FI2-7300 INT | FI2-7300 FiberInspector Pro V2 USB & WiFi MPO probe with tip set and Versiv 2 mainframe

Name: FI2-7300 INT | FI2-7300 FiberInspector Pro V2 USB & WiFi MPO probe with tip set and Versiv 2 mainframe
Brand: FLUKE Networks
SKU: FI2-7300 INT
Price: 7214.0 EUR
Availability: OutOfStock

Manufacturer number: FI2-7300 INT

Delivery time upon request

€7,214.00

plus VAT. €8,584.66 VAT plus shipping costs

You would like to request an offer? Please add items to the shopping cart and request an offer there.

FLUKE Networks FI2-7300-INT | FiberInspector Ultra Camera, Versiv mainframe and MPO / single fiber camera FI-3000, resolution 5 megapixels, USB & WLAN.

Version with measuring device: FI2-7300-INT FiberInspector Ultra Kit incl. Versiv mainframe, FI-3000 MPO / single fiber optic camera
Version without measuring device: FI-3000 MPO / single fiber optic camera, for use with smartphones
Supports one or two rows of 8, 12, 16, or single UPC or APC connectors
Resolution: 5 MPixel, 1/4 CMOS sensor
Light source: LED,> 100,000 hours service life
End face lighting: coaxial LED, blue; Port lighting: white LED
Battery: Lithium-ion battery, 10.8 h operating time
Field of view: 610 µm x 460 µm
Minimum detectable particle size: 1 µm
Interfaces: USB, WLAN (2.4 GHz)
Power supply: input 100 to 240 VAC, 50/60 Hz, output 15 VDC, 2 A max., Class II
Dimensions: W 133.3 x H 279.4 x D 66.7 mm (mainframe), W 137 x H 168 x D 54 mm (camera without dust cap)
Weight: 1.28 kg (mainframe with battery); 326 g (camera with dust cap, without adapter tip)

Independant Consulting

More than 50 strong brands and exclusive partnerships.

About the brands

Services

More than instruments: Before, during and after sales.

Go to the services

Demonstration & Consulting

Sales and technical support close to you.

Start request

Detaildescription

FI2-7300 INT | FI2-7300 FiberInspector Pro V2 USB & WiFi MPO probe with tip set and Versiv 2 mainframe

The FiberInspector Ultra is the complete solution for fiber optic inspection. The inspection camera supports both single fibers and MPO and offers an automated or quick manual inspection with the Versiv Cabling Certification System, LinkWare or your smartphone. The FiberInspector Ultra is available in two versions: The FI-3000 FiberInspector Ultra camera works with your smart mobile device, and the FI2-7300-INT FiberInspector Ultra Kit contains the FI-3000 camera and a Versiv 2 mainframe.

Faults in fiber optic cabling are mainly due to contaminated end faces. Dirt and impurities can cause insertion loss and reflections that hinder optical transmission and interfere with the operation of transceivers. In view of the ever higher data rates, the inspection of the end faces is therefore a particular focus. Impurities can be eliminated in good time before the optical fibers are inserted into a built-in connector or device.

The FiberInspector Ultra offers extensive functions for testing MPO trunks, cassettes and cable arrays or individual optical fibers. The multiple camera provides a live view of the entire end face on the Versiv or smartphone as well as a PASS / FAIL result per fiber within a few seconds. LinkWare Reporting Software can save full project reports including copper, fiber attenuation, OTDR and end face images. The results can also be saved on the mobile phone and forwarded.

Product features:

Complete solution for fiber inspection: robust FI-3000 camera with USB and WLAN, Versiv mainframe, MPO tips for 12/24 UPC and APC connectors, adapter for single fibers
Live view with autofocus and autocentering: Dual cameras offer an integrated view of the individual fiber or the entire MPO fiber end face in real time
Versiv Cabling Certification System and LinkWare Reporting Software: for easy operation, documentation and project management
Automated PASS / FAIL measurement of end faces according to industry standard IEC 61300-3-35 and display of defective optical fibers within seconds
iOS and Android apps for simple data sharing: simple connection of the FI-3000 camera with iOS or Android devices via WLAN for smaller jobs or quick inspection tasks
Light, ergonomic design with holster: with integrated PortBright lighting for optimal visibility on densely packed patch panels, in dark data centers or distribution cabinets

Lieferumfang

FI-3000 MPO / single fiber optic camera
Versiv 2 mainframe
C-cable for connecting the probe to the mainframe
Dummy module to protect the socket on the back of the mainframe
Test probe set (12/24 UPC and 12/24 APC)
Single fiber optic adapter for FI-1000 tips
AC charger
Shoulder strap
carry bag
USB cable
Versiv Open Source Software CD
quick start Guide

About the Manufacturer

FLUKE Networks

FLUKE Networks is a global leader in providing tools to certify, troubleshoot and install critical network cabling infrastructure. From installing the most advanced data centers to restoring phone service in bad weather conditions, the combination of unbeatable reliability and unparalleled performance ensures jobs get done efficiently.
