Cleverscope CS1070 | Signal amplifier DC up to 52 MHz, 36Vpp for CS700A or CS701 function generators

Manufacturer number: CS1070

CS1070
Delivery time upon request

On Request

or choose one of the following options:
Request a quote Product is already in cart
Product inquiries
Highlights Description Scope Related Articles

Cleverscope CS1070 | Signal amplifier DC up to 52 MHz, 36 Vpp for CS700A or CS701 function generators.

  • Gain factor 10 (20 dB)
  • Bandwidth 52 MHz
  • Input impedance: 50 Ω
  • Output impedance: 1 Ω
  • Rise time: 1700 V / µs
  • Output voltage 32 Vpp
  • Symmetrical output voltage range: from ± 5 V to ± 18 V
  • Asymmetrical output voltage range: from: from + 31 V to - 5V

Description

CS1070 | Signal amplifier DC up to 52 MHz, 36Vpp for CS700A or CS701 function generators

The CS1070A power amplifier is intended as an output amplifier for Cleverscope's CS700A and CS701A signal generators. The bandwidth of the amplifier is 52 MHz and provides an output voltage of 32 Vpp with a maximum output current of 1 A. The amplifier contains an inverting power supply to meet a simple negative supply for power supply requirements. The gain is fixed at a factor of 10 (20 dB). The output voltage range is ± 5 V to ± 18 V and asymmetrical from + 31 V to - 5V for PSRR (Power Supply Rejection Ratio) measurements up to 30 V.

Lieferumfang

  • Power supply with EU, US, UK network adapters; Input voltage 90-264 VAC, 47-63 Hz
