B&K Precision 5492CGPIB | Bench Multimeter, TRMS, 5.5 Digits, USB, RS-232, LAN, GPIB, 5490C Series

Name: 5492CGPIB | Bench Multimeter, TRMS, 5.5 Digits, USB, RS-232, LAN, GPIB, 5490C Series
Brand: B&K Precision
SKU: BK5492CGPIB
Price: 1050.0 EUR
Availability: InStock

Manufacturer number: BK5492CGPIB

Delivery time upon request

€1,050.00

plus VAT. €1,249.50 VAT plus shipping costs

or choose one of the following options:

Request a quote Product inquiries Request education-price

B&K Precision 5492CGPIB | Bench multimeter, TRMS, 5.5 digits, USB, RS-232, LAN, GPIB.

Technical Data

2-/4-wire:	2-/4
Accuracy voltage measurement DC:	0,010 %
Article number:	BK5492CGPIB
Capacity measuring range:	0.1 pF - 10 mF
Current measuring range AC:	100 µA - 10 A
Current measuring range DC:	100 µA - 10 A
Dimensions (L x W x H) (mm):	355 x 225 x 100
Diode test / continuity test:	Yes / Yes
Display:	LCD, dual
Frequency measuring range:	3.3 Hz - 1 MHz
Interfaces:	USB, LAN, RS-232, GPIB
Measurements per second:	1,000
Model:	BK5492CGPIB
Number of positions:	5.5
Resistance measuring range:	10 Ω - 100 MΩ
Temperature measurement:	Yes
Voltage measuring range AC:	100 mV - 750 V
Warranty (years):	3
Weight (kg):	2.5
max. Measuring range DC (V):	1,000
min. Measuring range DC (mV):	100

Documents & Downloads

Datasheet

pdf | 1.79 MB

Description

5492CGPIB | Bench Multimeter, TRMS, 5.5 Digits, USB, RS-232, LAN, GPIB, 5490C Series

The 5492CGPIB model is a high-precision 5½-digit benchtop digital multimeter in the 5490C series from B&K Precision and has an integrated GPIB interface in addition to the standard features. It is ideal for automated test environments in laboratories, production and development and impresses with its reliability, versatility and user-friendliness.

With twelve integrated measurement functions, extensive analysis modes (such as trend chart, histogram and statistics functions) and a dual measurement display, the device offers a wide range of applications. The GPIB interface allows easy system integration into existing automated measurement systems.

Product features:

Resolution: 5½-digit
Basic accuracy DCV: ±0.010 % (100 ppm)
Measurement functions: DCV, ACV, DCI, ACI, 2-/4-wire resistance, capacitance, frequency, temperature, diode test, continuity, DCV ratio
Measurement speed: up to 1000 measured values per second
Display: 4.3" high-contrast color display with histogram, trend chart and bar graph
Dual measurement: simultaneous display of two measured values
Data memory: 10.000 measured values with time/date stamp in the internal buffer
Communication interfaces: USB (USBTMC), RS232, LAN, GPIB
LabVIEW™ driver available for easy integration into automated measurement systems
Dimensions (W×H×D): 225 × 100 × 355 mm | Weight: 2.5 kg

The 5492CGPIB variant supplements the basic 5492C model with a professional GPIB interface, making it particularly interesting for automated test benches. Compared to the higher-resolution models 5493C and 5493CGPIB (6½-digit), the 5492CGPIB offers a more cost-effective alternative with very good measurement performance. However, rear input terminals are only reserved for the 6½-digit models. If you are looking for high connectivity combined with robust precision, the 5492CGPIB is a reliable measuring device with a wide range of applications.
