The DPO70000SX series oscilloscopes offer you real-time signal acquisition with ultra-high bandwidths up to 70 GHz. The patented High Performance ATI technology (Asynchronous Time Interleaving, device models DPO77002SX / DPO75902SX / DPO75002SX) enables excellent signal fidelity with a minimal noise figure. B. for coherent optical modulation analysis, for debugging serial high-speed buses and for compliance tests, for bit error detection or for PAM4 and NRZ measurements.
Outstanding signal integrity:
- High-performance trigger system for isolating signal errors
- Outstanding timing accuracy
- Precise time base accuracy
- Channel runtime differences / timing
- Timing stability in systems with multiple device units
- Low-noise optical measurements with the DPO7OE1 optical probe
Powerful, advanced analysis functions:
- High-precision jitter and noise analysis as well as optical measurements with DPOJET
- Analysis and compensation of signal influences in serial data connections (SDLA)
- Comprehensive PAM4 analysis without an external CR unit
- Support for all standards for Gen3 / Gen4 +
- Automated conformity check for reproducible results
- Powerful debugging tools to quickly identify and fix design problems
Flexible multi-device configuration:
The innovative UltraSync architecture allows you to flexibly configure up to four device units so that you can easily add acquisition channels (max. 16 channels in total) while maintaining excellent timing accuracy between the channels.
- Compact design with only 3 height units (3 U)
- Simple aggregation in a system with up to 4 units
- Quick reconfiguration of the system
- Configure up to 16 synchronized optical acquisition channels with DPO7OE1 / DPO7OE2 probe
