NI 783951-01 | NI 9476E, digital output module, 24 V, 500 us, 32 channels, supplying current, card only

Name: 783951-01 | NI 9476E, digital output module, 24 V, 500 us, 32 channels, supplying current, card only
Brand: NI
SKU: 783951-01
Price: 640.0 EUR
Availability: InStock

Manufacturer number: 783951-01

Delivery time upon request

€640.00

or choose one of the following options:

Request a quote Product inquiries Request education-price

783951-01 | NI 9476E, digital output module, 24 V, 500 us, 32 channels, supplying current, card only.

Technical Data

Bustype:	C Series
Connection type front:	37-pin, male D-Sub
Isolation of the digital I/O:	60 VDC Channel insulation to ground
Logic level and range:	12 V, 24 V, 6.0V - 36.0V
Logic level of the digital I/O:	24 V, 12 V
Module width:	0
Number of bidirectional digital channels:	0
Number of digital inputs:	0
Number of digital outputs:	32
Protectively coated:	No
Warranty (years):	1
Weight (kg):	0.08
With case:	No

Description

783951-01 | NI 9476E, digital output module, 24 V, 500 us, 32 channels, supplying current, card only

The sbRIO ‑ 9476 works with industrial logic levels and signals so that it can be connected directly to a large number of industrial switch modules, converters and other devices. Each channel is compatible with signals from 6 V to 36 V, depending on the external power supply, and has overvoltage protection against transients between the output channels and the backplane. The integrated protection against overvoltage and short circuits can be monitored programmatically for each channel. Modules without a housing were designed for OEM applications.

Product features:

Number of pure digital input channels: 0
Number of pure digital output channels: 32
Number of bidirectional digital channels: 0
Logic level of the digital I / O: 12 V 24 V.
Maximum update rate: 500 µs
Direction of current flow: output supplying current
Isolation of the digital I / O: 60 VDC isolation of the channel from ground
Connection type front: D-Sub
Protective coating: no
With housing: No.
Supported hardware platform: CompactRIO
