NI 782718-01 | NI 9234E, IEPE module, 4 channels, 24 bit, ± 5 V, board only

Name: 782718-01 | NI 9234E, IEPE module, 4 channels, 24 bit, ± 5 V, board only
Brand: NI
SKU: 782718-01
Price: 3240.0 EUR
Availability: InStock

Manufacturer number: 782718-01

Delivery time upon request

€3,240.00

or choose one of the following options:

Request a quote Product inquiries Request education-price

782718-01 | NI 9234E, IEPE module, 4 channels, 24 bit, ± 5 V, board only.

Technical Data

Analogue input isolation:	Without, nan
Bustype:	C Series
Connection type front:	1-pin, female BNC
IEPE excitation (mA):	2
Max. Number of differential analogue input channels:	4
Measured electrical signal:	Voltage
Measurements per second/sampling rate (MS/s):	0.0512
Module width:	0
Protectively coated:	No
Resolution of the analogue input:	24 bit
Samplerate:	51.2 kS/s per channel
Voltage measuring range of the analogue input (V):	-5 V to 5 V
Warranty (years):	1
Weight (kg):	0.12
With case:	No

Description

782718-01 | NI 9234E, IEPE module, 4 channels, 24 bit, ± 5 V, board only

The sbRIO-9234 module is suitable for industrial measurements with IEPE and non-IEPE sensors such as accelerometers, tachometers and non-contact probes. The sbRIO ‑ 9234 is also compatible with intelligent TEDS sensors. The sbRIO ‑ 9234 offers a large dynamic range and software selectable AC / DC coupling and IEPE signal conditioning. Signals are measured simultaneously on the input channels. All channels also have anti-aliasing filters that are automatically adjusted to the sample rate. When used with NI software, this module provides condition monitoring processing functions such as frequency and order analysis. Modules without a housing are designed for OEM applications.

Product features:

Maximum number of differential analog input channels: 4
Maximum sampling rate: 51.2 kS / s per channel
Voltage measuring range of the analog input: -5 V to 5 V.
Isolation of the analog input: none
IEPE excitation: 2 mA
Connection type front: BNC (qty 4)
Protective coating: no
With housing: No.
Supported hardware platform: CompactRIO

Accessoires

NI
960460-01

Traceable Calibration Certificate for sbRIO-9234 (782718-01-CAL)

Delivery time upon request

€285.00

NI
960460-04

ISO 17025 Calibration Certificate for sbRIO-9234 (782718-01-ISO)

Delivery time upon request

€565.00

NI
960680-100

Standard Service Program (SSP) for sbRIO-9234, 3 years (782718-01-S3)

Delivery time upon request

On Request

NI
960460-03

ANSI Compliant Calibration Certificate for sbRIO-9234 (782718-01-ANSI)

Delivery time upon request

€440.00

NI
960680-101

Standard Service Program (SSP) for sbRIO-9234 with Traceable Calibration, 3 years (782718-01-SC3)

Delivery time upon request

€1,114.20

About the Manufacturer

National Instruments is a global leader in test, measurement, and control solutions. NI's platform-based approach combines modular hardware and software to help customers address complex engineering challenges. Applications range from automotive, electronics, and energy to research/education and industrial systems.
