NI 779940-01 | NI 9478, current sinking digital output module, 16 channels, 0–50 V, 1.2 A per channel, 7 µs

Name: 779940-01 | NI 9478, current sinking digital output module, 16 channels, 0–50 V, 1.2 A per channel, 7 µs
Brand: NI
SKU: 779940-01
Price: 1270.0 EUR
Availability: InStock

Manufacturer number: 779940-01

Delivery time upon request

€1,270.00

or choose one of the following options:

Request a quote Product inquiries Request education-price

779940-01 | NI 9478, current sinking digital output module, 16 channels, 0–50 V, 1.2 A per channel, 7 µs.

Technical Data

Bustype:	C Series
Connection type front:	37-pin, male D-Sub
Isolation of the digital I/O:	60 VDC Channel insulation to ground
Logic level and range:	48 V, 24 V, 5.0V - 50.0V, 12 V
Logic level of the digital I/O:	48 V, 24 V, 12 V
Module width:	1
Number of bidirectional digital channels:	0
Number of digital inputs:	0
Number of digital outputs:	16
Protectively coated:	No
Warranty (years):	1
Weight (kg):	0.18
With case:	Yes

Description

779940-01 | NI 9478, current sinking digital output module, 16 channels, 0–50 V, 1.2 A per channel, 7 µs

The NI ‑ 9478 uses industrial logic levels and signals so it can be connected directly to a wide variety of industrial relays, solenoids, and motors. It has programmable current limits for user-defined system protection when controlling solenoids and valves. Each channel is compatible with signals from 5 V to 50 V and is isolated from the channel to ground.

Product features:

Number of pure digital input channels: 0
Number of pure digital output channels: 16
Number of bidirectional digital channels: 0
Logic level of the digital I / O: 12 V 24 V 48 V.
Maximum update rate: 50 µs
Current flow direction: current sinking output
Isolation of the digital I / O: 60 VDC isolation of the channel from ground
Connection type front: D-Sub
Protective coating: no
With housing: yes
Supported hardware platform: CompactDAQ, CompactRIO
