NI 779005-01 | NI 9411 differential SE digital input module for 6 channels (± 5-24 V, 1 MHz)

Name: 779005-01 | NI 9411 differential SE digital input module for 6 channels (± 5-24 V, 1 MHz)
Brand: NI
SKU: 779005-01
Price: 420.0 EUR
Availability: InStock

Manufacturer number: 779005-01

Delivery time upon request

€420.00

or choose one of the following options:

Request a quote Product inquiries Request education-price % Additional offers for this product

779005-01 | NI 9411 differential SE digital input module for 6 channels (± 5-24 V, 1 MHz).

Technical Data

Bustype:	C Series
Connection type front:	15-pin, male D-Sub
Isolation of the digital I/O:	60 VDC Channel insulation to ground
Logic level and range:	RS-422, 5 V TTL, 12 V, 24 V, 5 V
Logic level of the digital I/O:	RS-422, 5 V TTL, 12 V, 24 V, 5 V
Module width:	1
Number of bidirectional digital channels:	0
Number of digital inputs:	6
Number of digital outputs:	0
Protectively coated:	No
Warranty (years):	1
Weight (kg):	0.19
With case:	Yes

Description

779005-01 | NI 9411 differential SE digital input module for 6 channels (± 5-24 V, 1 MHz)

The NI ‑ 9411 uses industrial logic levels and signals so it can be connected directly to a wide variety of industrial switch modules, converters, and other devices. The NI ‑9411 is a correlated digital module that enables correlated measurements, triggering and synchronization when installed in a CompactDAQ chassis

Product features:

Number of pure digital input channels: 6
Number of pure digital output channels: 0
Number of bidirectional digital channels: 0
Logic level of the digital I / O: RS-422 5V TTL 5V 12V 24V
Maximum update rate: 500 ns
Current flow direction: Current sinking input
Isolation of the digital I / O: 60 VDC isolation of the channel from ground
Connection type front: D-Sub
Protective coating: no
With housing: yes
Supported hardware platform: CompactDAQ, CompactRIO
