The Fluke 15B+ is a robust, portable digital multimeter for everyday electrical testing in the trade, in maintenance and in the demanding DIY sector. It offers all basic measurement functions in an easy-to-use device that can be used optimally even under difficult working conditions thanks to its large display and ergonomic design.
With its CAT III 600 V safety specification, it is ideal for testing domestic installations, distribution boards, sockets, switches, industrial control systems and electrical devices. Typical applications are:
- Voltage tests on household and industrial installations
- Testing motor connections and power supply units
- Resistance and continuity measurements on cables and fuses
- Capacitance measurement on capacitors in control and electronic circuits
- General current measurements in AC and DC circuits
The Fluke 15B+ offers AC and DC voltage measurement up to 1.000 V and AC and DC current measurement up to 10 A. It also has functions for resistance, continuity, capacitance, diode test and hold function. The backlit 4000-count display ensures excellent readability, even in poorly lit working environments.
The robust, non-slip housing is specially designed for daily use in the electrical trade and reliably protects the device from external influences.
The model 15B+ presented here and its sister model 17B+ belong to the same product family. Both offer voltage and current measurements up to 1,000 V and 10 A respectively, a backlit display and basic electrical measurement functions.
The Fluke 17B+ offers additional diagnostic functions and extended measurement options compared to the 15B+:
- Temperature measurement
- Frequency measurement
- Duty cycle measurement
- Relative value mode (REL)
- MIN/MAX recording
This makes the 17B+ particularly suitable for electronics engineers and service technicians who perform more complex measurement tasks. The 15B+, on the other hand, is the price-conscious choice for classic electrical installation work and basic testing tasks.
Product features:
- Safety specification: CAT III 600 V
- AC/DC voltage measuring ranges: 4.000 V / 40.00 V / 400.0 V / 1000 V
- AC/DC current measurement ranges: 400.0 µA to 10.00 A
- Resistance measurement: 400.0 Ω to 40.00 MΩ
- Capacitance measurement: 40.00 nF to 1000 µF
- Diode test function
- Acoustic continuity test
- Hold function for measured value storage
- Display with 4000 counts and backlight
- Maximum permissible input voltage: 1000 V
- Operation with 2 × AA batteries, typ. Operating time approx. 500 h
- Operating temperature: 0 °C to 40 °C
- Protection class: IP40
- Dimensions: approx. 183 × 91 × 49.5 mm
- Weight: approx. 455 g
- Fuses: 440 mA and 11 A, 1000 V
- Compliant with IEC 61010-1 and IEC 61010-2-030
