B&K Precision 9131C | DC Power Supply Unit, 3 Channel, Programmable, 2 x 30 V / 1 x 5 V, 2 x 6 A / 1 x 3A, 375 W, USB, RS-232, 9130C Series

Manufacturer number: BK9131C

9131C
9131C
Series
Delivery time upon request

€1,750.00

or choose one of the following options:
Request a quote Product is already in cart
Product downloads Product inquiries Request education-price
Highlights Technical Data Documents / Downloads Description Related Articles

B&K Precision 9131C | DC power supply unit, 3 channel, programmable, 2 x 30 V / 1 x 5 V, 2 x 6 A / 1 x 3A, 375 W, USB, RS-232.

Technical Data

Documents & Downloads

Datasheet
BK9130C
pdf | 1.84 MB

Description

9131C | DC Power Supply Unit, 3 Channel, Programmable, 2 x 30 V / 1 x 5 V, 2 x 6 A / 1 x 3A, 375 W, USB, RS-232, 9130C Series

The 9131C from the 9130C series from B&K Precision is a triple programmable laboratory power supply with electrically isolated outputs and an extended current range. With up to 6 A on the main channels, the model offers significantly more power for current-intensive applications. Ideally suited for power electronics, test environments, R&D, service laboratories and automated test systems, this power supply unit impresses with its precise regulation, simple operation, extensive protection functions and flexible combination options for the channels.

Product features:

  • 3 independent, isolated outputs (2 x 0-30 V / 6 A, 1 x 0-5 V / 3 A)
  • Total power: 375 W
  • Resolution: 1 mV / 1 mA
  • Programming and reading accuracy: up to ±0.03% + 10 mV (voltage), ±0.1% + 8 mA (current, CH1 & CH2)
  • Series and parallel operation for voltage or current increase
  • Tracking mode for synchronous control of multiple channels
  • Timer function: 0.1 - 99999.9 seconds
  • Memory: 4 groups with 9 storable configurations each
  • Interfaces: USB (USBTMC), RS232, SCPI compatible
  • Dimensions: 214.5 x 88.2 x 445 mm (W x H x D)
  • Weight: 15 kg

Compared to the base model 9130C, the 9131C doubles the maximum current output of the two main channels from 3 A to 6 A, making it particularly suitable for applications with higher loads. The voltage ranges remain the same (30 V at CH1/CH2, 5 V at CH3). The 9132C model, on the other hand, offers higher voltages of up to 60 V with the same current. This makes the 9131C ideal for high-current applications, while the 9132C is designed for applications with higher voltage requirements. All three models offer the same control and protection functions.
