Spectrum Analysis / EMC

Spectrum analyzers for displaying and analyzing the frequencies contained in a signal. Ideal for development, EMC measurements and telecommunications.

279 products

LANGER
RF-K 7-4

H-field probe, 30 MHz to 1 GHz

CHF 328.00

Delivery time upon request

Exclusive

GW Instek
GSP-9330-03

Option GPIB interface for GSP-9330 spectrum analyzer

CHF 303.00

Delivery time upon request

LANGER
SX-R 3-1

H-field probe, 1 GHz to 10 GHz

CHF 678.00

Delivery time upon request

Shieldex
RF-X TERMINAL

Shielded terminal block for I/O panel power without connectors

CHF 435.00

Delivery time upon request

Rohde&Schwarz
FSC-B22

RF preamplifier, gain 20dB, 9 kHz - 3 / 6 GHz, for FSC3/6, retrofit (1314.3535.03)

CHF 591.00

Delivery time upon request

Detectus
HRE-43 / 3G

Near field scanner 4D, EMC, high resolution, HRE-43 SE 3 GHz, scanning area 390 x 290 x 130 mm

min. Step size (mm): 0.025
Scan type: 3D
Interfaces: RS-232, LAN
Scanning area (X,Y,Z) (mm): 390 x 280 x 130
Bandwidth (GHz): 3

On Request

Delivery time upon request

GW Instek
GSP-818TG

Spectrum analyzer, 9 kHz - 1.8 GHz, tracking gen. LAN / USB, AM / FM, -148 to +30 dBm

Tracking-Generator: Yes
SSB phase noise: -82 dBc/Hz @ 1 GHz (10 kHz carrier offset)
Sweep: linear
Detectors: Peak, RMS, Quasi-Peak
DANL Displayed Average Noise: ca. -130 dBm
Filter bandwidths: 10 Hz - 500 kHz 1-10 sequence, EMI 200 Hz, 9 kHz, 120 kHz, 1 MHz
max. Frequency range (GHz): 1.8
Resolution bandwidth: 10 Hz
Measurement functions: AM/FM Demodulation & Analysis, Channel Power, N-dB Bandwidth, OCBW, ACPR, SEM, TOI, CNR, CTB, CSO, Noise Marker, Frequency Counter, Time Domain Power
Amplitude range: -80 dBm to 30 dBm
Dynamics: 110 dB
min. Frequency range (kHz): 9
Frequency stability: 2,5 ppm
Interfaces: USB, LAN, VGA
