Pico PQ421 | PicoScope 5464E+ kit USB oscilloscope, 500 MHz (8-bit), 4 channels (analog), 8-bit (2 GS) and 16-bit (1 GS) resolution

Name: PQ421 | PicoScope 5464E+ kit USB oscilloscope, 500 MHz (8-bit), 4 channels (analog), 8-bit (2 GS) and 16-bit (1 GS) resolution
Brand: Pico
SKU: PQ421
Price: 5109.0 CHF
Availability: InStock

Manufacturer number: PQ421

Delivery time upon request

CHF 5,109.00

plus VAT. CHF 5,522.83 VAT plus shipping costs

or choose one of the following options:

Request a quote Product inquiries Request education-price

PicoScope PQ421 | 5464E+ kit USB oscilloscope, 500 MHz (8-bit), 4 channel (analog), 8-bit (2 GS) and 16-bit (1 GS) resolution.

Technical Data

Article number:	PQ421
Bandwidth (MHz):	500
Counter:	Yes
DVM:	Yes
Dimensions (L x W x H) (mm):	221 x 173 x 30
Function generator:	Yes
Interfaces:	USB
Model:	5464E+ kit
Number of channels:	4
Samplerate:	1 GSa/s
Segmentable memory:	Yes
Signal acquisition rate:	300,000 wfms/s
Storage depth:	4 GPts
Supporting serial buses:	I²C, SPI, UART, CAN, LIN, FlexRay
Triggertypes:	None, auto, repeat, single, rapid, Edge, window, pulse width, window pulse width, level dropout, window dropout, interval, runt, transition time, logic
Vertical resolution:	16-bit
Warranty (years):	5
Weight (kg):	1.49

Description

PQ421 | PicoScope 5464E+ kit USB oscilloscope, 500 MHz (8-bit), 4 channels (analog), 8-bit (2 GS) and 16-bit (1 GS) resolution

The PicoScope 5000E series comprises high-resolution PC-based oscilloscopes designed for precise measurements and fast signal analysis. The instruments combine 16-bit resolution with high sampling rates, large memory, and extensive analysis capabilities. Thanks to low inherent noise and a wide dynamic range, these oscilloscopes are particularly well-suited for demanding applications in development, research, embedded systems, and industry.

The series features extensive trigger functions, FFT spectrum analysis, serial protocol decoding, DeepMeasure analysis, Math channels, and integrated function and arbitrary waveform generators. The Plus models extend the classic 16-bit architecture with a powerful 8-bit mode featuring higher bandwidth, higher sampling rates, and double the memory. This allows both high-precision analog signals and fast digital and near-RF signals to be analyzed with a single instrument.

Differences from the other variants

The PicoScope 5464E+ is the most powerful model in the PicoScope 5000E+ series. In 16-bit mode, the device offers a bandwidth of 200 MHz for high-precision measurements. Additionally, an 8-bit high-speed mode is available with up to 500 MHz bandwidth and a sampling rate of up to 5 GS/s. This makes the model ideal for demanding laboratory, development, and RF applications.

Compared to the 5462E+ and 5463E+, the 5464E+ offers the highest bandwidth and the fastest rise time within the entire 5000E+ series. At the same time, the instrument features expanded memory and the flexibility to switch between high-resolution 16-bit precision and maximum speed in 8-bit mode.

Product Features:

Channels: 4 analog inputs
Bandwidth: 200 MHz in 16-bit mode
Bandwidth: 500 MHz in 8-bit mode
Vertical resolution: 8-bit and 16-bit
Extended vertical resolution: Hardware resolution + 4 bits via software
Maximum sampling rate: 2.5 GS/s in 16-bit mode, up to 5 GS/s in 8-bit mode
Memory: up to 1 GS per channel in 16-bit mode, up to 2 GS per channel in 8-bit mode
Rise time: 1.75 ns in 16-bit mode, 925 ps in 8-bit mode
Selectable bandwidth limits: 20 MHz, 60 MHz, 100 MHz, and 200 MHz in 16-bit mode; additionally 350 MHz and 500 MHz in 8-bit mode
Input connector: BNC jack
Input impedance: 50 Ω ±2% or 1 MΩ ±1% || 13 pF ±2 pF
Input coupling: DC at 50 Ω, AC/DC at 1 MΩ
Input sensitivity: 1 mV/div to 1 V/div at 50 Ω, 1 mV/div to 4 V/div at 1 MΩ
Input ranges: up to ±5 V at 50 Ω, up to ±20 V at 1 MΩ
DC gain accuracy: ±(0.5% of the signal + 1 LSB)
RMS noise: from 0.022 mV in low voltage ranges
FFT spectrum analysis with up to 1 million FFT points
Trigger types: Edge, Window, Pulse Width, Dropout, Runt, Interval, and Logic triggers
Function generator up to 20 MHz with sine, square, triangle, and other waveforms
Arbitrary waveform generator: 200 MS/s, 32 kS memory, 14-bit resolution
Serial protocol decoding for CAN, CAN FD, LIN, SPI, I²C, UART, FlexRay, Ethernet, and other standards
Hardware-accelerated display of over 2 GS of data per second in 8-bit mode
PC connection: USB 3.0 SuperSpeed via USB-C, USB 2.0 compatible
Dimensions: 221 × 173 × 30 mm
Weight: less than 0.7 kg
Operating temperature: 0 to 40 °C
Warranty: 5 years
