NI 779001-01 | NI 9211, thermocouple / analog input module for differential signals, 4 channels, ± 80 mV, 14 S / s, 24 bit

Name: 779001-01 | NI 9211, thermocouple / analog input module for differential signals, 4 channels, ± 80 mV, 14 S / s, 24 bit
Brand: NI
SKU: 779001-01
Availability: InStock

Manufacturer number: 779001-01

2 in stock. Ready to ship in 1 business day

On Request

or choose one of the following options:

Request a quote Product inquiries Request education-price

NI 779001-01 | NI 9211, thermocouple / analog input module for differential signals, 4 channels, ± 80 mV, 14 S / s, 24 bit.

Technical Data

Analogue input isolation:	Ch-Earth Ground Isolation, 250 Veff Isolierung Kanal gegen Masse
Bustype:	C Series
Connection type front:	10-Pin, Weiblich Schraubanschluss
Max. Number of differential analogue input channels:	4
Measurements per second/sampling rate (MS/s):	0.000014
Module width:	1
Protectively coated:	No
Resolution of the analogue input:	24 bit
Samplerate:	14 S/s
Supported sensors:	All Standard Thermocouples
Warranty (years):	1
With case:	Yes

Description

779001-01 | NI 9211, thermocouple / analog input module for differential signals, 4 channels, ± 80 mV, 14 S / s, 24 bit

The NI-9211 module offers anti-aliasing filters, detection of open thermocouples, and cold junction compensation for thermocouple measurements with high accuracy. The NI-9211 module also has a NIST-compliant calibration certificate and double insulation of the channel from ground, which ensures increased operational reliability, noise immunity and a high common-mode voltage range.

Accessoires

NI
960680-100

Standard Service Program (SSP) for NI-9211, 3 Year (779001-01-S3)

Delivery time upon request

On Request

NI
960460-04

ISO 17025 Calibration Certificate for NI-9211 (779001-01-ISO)

Delivery time upon request

€565.00

NI
960680-101

Standard Service Program (SSP) for NI-9211 with Traceable Calibration, 3 Years (779001-01-SC3)

Delivery time upon request

€915.80

NI
960460-03

ANSI Compliant Calibration Certificate for NI-9211 (779001-01-ANSI)

Delivery time upon request

€440.00

NI
960460-01

Traceable Calibration Certificate for NI-9211 (779001-01-CAL)

Delivery time upon request

€285.00
