GW Instek GLC-9000 | Leakage current tester AC/DC 25mA, 75mA AC PEAK measurement.
Depending on the applicable test standard, the safety test on electrical devices must be completed with a leakage current measurement with an increased nominal voltage after the test on the de-energized device. Only the leakage current test enables the activation of internal switching elements in electrotechnical devices.
The GCL9000 enables tests according to IEC 60601-1 and IEC 60990, among others. Here, the human body is simulated with its dissipative properties.
Equipment and highlights:
- Leakage currents DC 50µA/500µA/5mA/25mA
- Leakage currents AC 50µA/500µA/5mA/25mA
- PEAK measurement AC up to 75mA
- Grounded outputs
- Voltmeter 10 to 300V AC/DC (PEAK AC 15 to 430V)
- Color LCD 320x240 pixels with touch function for easy operation
- 9 different test presets to simulate the human body
- 8 different types of leakage current for medical and other electrical equipment
- IEC60601-1/60990/60335-1/UL554NP/UL1563 etc.
- Adjustable lower and upper limit for the "good" / "bad" assessment
- 50 preset test sequences to meet the IEC 60990 standard
- 30 freely programmable test sequences
- GPIB, USB and RS232 interface
- Dimensions: 330 x H 150 x D 350 mm
- Scope of delivery: safety tester, operating instructions, mains cable, 2x measuring line set GTL-207, 4 crocodile clips, foil sample
