The Fluke 302+ digital current clamp meter is a compact, robust measuring device for fast and reliable current and voltage measurements in everyday use. Thanks to the non-contact current measurement via the clamp, conductors can be tested safely without interrupting the circuit. The high protection class and clear display make the device ideal for maintenance, installation and troubleshooting in electrical systems.
The Fluke 302+ is specially designed for electricians, service technicians and maintenance engineers who need a handy measuring device for routine tests. It covers typical tasks in residential and commercial buildings as well as work on switch cabinets, smaller machines and distribution boards.
- Quickly check load currents on cables, fuses, motors and distribution boards
- Voltage and resistance measurements in installations, control circuits and terminal strips
- Circuit continuity tests during troubleshooting, e.g. on cables, contacts and terminal strips
- . e.g. on cables, contacts and fuses
- Use in general electrical maintenance, building management and technical service
The Fluke 302+ measures alternating currents up to 400 A and is therefore ideally suited for most standard applications in the electrical trade. The 30 mm clamp makes it possible to grip conductors of medium cross-section without having to disconnect them. The backlit display ensures that the measured values are easy to read even in poorly lit environments, while the data hold function makes it easy to record measured values.
With its safety specification up to CAT IV 300 V/CAT III 600 V, the current clamp meter is designed for measurements in building installations and in distribution boards with high safety requirements. The compact design fits comfortably in the tool bag and is robust enough for daily use on the construction site or in the workshop.
Product features:
- Measuring range alternating current: up to 400.0 A
- Actuating current accuracy: 1.8 % ± 5 digit
- Actuating voltage measuring ranges: 400 V / 600 V
- Actuating voltage accuracy: 1.5 % ± 5 digit
- Direct voltage measuring ranges: 400 V / 600 V
- Direct voltage accuracy: 1.5 % ± 5 digit
- Resistance measurement: up to 4000 Ω
- Resistance accuracy: 1 % ± 5 digit
- Circuit continuity test: Triggered at ≤ 70 Ω
- Backlit display for easy readability
- Data hold function for measured value
- Dimensions (H x W x D): 208 x 58.5 x 28 mm
- Clamp size: 30 mm conductor diameter
- Safety specification: CAT IV 300 V / CAT III 600 V
- Operating temperature: 0 °C to 40 °C
- Screen refresh rate: > 2 readings per second
- Power supply: 2 AAA alkaline batteries
