LCR Meters and Impedance Analyzers

Characterize the passive components in your circuits with precision using our LCR Meters and Impedance Analyzers. The LCR Meter is a fundamental tool for accurately measuring Inductance (L), Capacitance (C), and Resistance (R), as well as secondary parameters like Dissipation Factor (D) and Quality Factor (Q). For more advanced material science, component testing, or high-frequency characterization, our Impedance Analyzers offer measurement across a broad frequency sweep.

89 products

Keysight
E4980BL

Precision LCR Meter, Basic Device

€423.00

Reordered - in stock. Delivery time on request

Keysight
E4980B

Precision LCR Meter / Component Tester, 20 Hz - 2 MHz

€25,838.00

Delivery time on request

Rohde&Schwarz
LCX100

LCR meter, DC, 4 Hz - 300 kHz, 0.05% accuracy, LAN, USB, optional GPIB (3629.8856.02)

DC Bias: internal: 0 - 10 V / external: 0 - 40 V
Measurement functions: D, Q, G, R, X, Z, Y, θ, B, M, N
min. Frequency range (Hz): 4
Handlerinterface: Yes
Special features: graphic touchscreen Data recording (logging) Sweep function
Interfaces: LAN, USB, GPIB
max. Frequency range (MHz): 0.3
Listsweep: Yes
Resolution: 5-digits
Accuracy: 0,05 %

€3,400.00

2 in stock. Ready to ship in 1 business day

Exclusive

Keysight
E4980A

LCR meter / component tester, 20 Hz to 2 MHz, opt. DC bias

Handlerinterface: Yes
Interfaces: LAN, USB, GPIB
Accuracy: 0,05 %
Measurement functions: Z, L, C, R, D, Q, θ, X, Y, G, B, D, ESR, RDC with option 001: Vdc / Idc
max. Frequency range (MHz): 2
Listsweep: Yes
Special features: shortest measurement time: 5.6 ms
min. Frequency range (Hz): 20
DC Bias: (0 - 2 V), with option 001: (-40 V - +40 V)
Resolution: 4-digits

Offer Request

3 in stock. Ready to ship in 1 business day

Keysight
U1733P

Handheld LCR meter, 100/120 Hz, 1/10/100 kHz, combo kit

€944.00

Delivery time on request

Keysight
U1731P

Handheld LCR meter, 100/120 Hz, 1 kHz, combo kit

€759.00

Delivery time on request

Keysight
U1732C

Handheld LCR meter, 100/120 Hz, 1/10 kHz

Resolution: 20,000 jobs
min. Frequency range (Hz): 100
Measurement functions: Z, L, C, R, D, Q, θ, ESR
Accuracy: 0,2 %
max. Frequency range (MHz): 0.01

€629.00

Delivery time on request

Rohde&Schwarz
LCX200

LCR meter, DC, 4 Hz - 500 kHz (10 MHz opt.), 0.05% accuracy, LAN, USB, optional GPIB (3629.8856.03)

DC Bias: internal: 0 - 10 V / external: 0 - 40 V
Measurement functions: D, Q, G, R, X, Z, Y, θ, B, M, N
min. Frequency range (Hz): 4
Handlerinterface: Yes
Special features: graphic touchscreen Data recording (logging) Sweep function
Interfaces: LAN, USB, GPIB
Resolution: 5-digits
Accuracy: 0,05 %
Listsweep: Yes
max. Frequency range (MHz): 0.5

€5,620.00

3 in stock. Ready to ship in 1 business day

Keysight
U1733C

Handheld LCR meter, 100/120 Hz, 1/10/100 kHz

Resolution: 20,000 jobs
min. Frequency range (Hz): 100
Accuracy: 0,2 %
Measurement functions: Z, L, C, R, D, Q, θ, ESR, DCR
max. Frequency range (MHz): 0.1

€718.00

Delivery time on request

Exclusive

Keysight
E4982A

HF-LCR meter, 1 to 300/500 MHz / 1 or 3 GHz

Handlerinterface: Yes
Interfaces: LAN, USB, GPIB
Listsweep: Yes
Special features: shortest measurement time: 0.9 ms, simultaneous display of test parameters, simultaneous display of 4 measurement results, TFT touchscreen Frequency option selectable: 1 MHz - 300 MHz; 500 MHz; 1 GHz; 3 GHz
Accuracy: 0,8 %
Resolution: 1 kHz
min. Frequency range (Hz): 1000000
DC Bias: No
Measurement functions: Z, L, C, R, D, Q, θ, X, G, B, D

Offer Request

Delivery time on request

Exclusive

Keysight
E4981A

Capacitance tester, 120 Hz / 1 kHz or 1 MHz

Handlerinterface: Yes
Interfaces: LAN, USB, GPIB
Listsweep: Yes
DC Bias: No
Accuracy: 0,07 %
Measurement functions: C, R
Special features: Frequency options: Option 001: 120 Hz / 1 kHz / 1 MHz Option 002: 120 Hz / 1 kHz
