Frequency and Resilient Timing

Our range of frequency counters, resilient timing solutions, and frequency standards ensure that you get precise measurements and reliable time synchronization. Whether you’re working with high-frequency signals or need a robust timing system for mission-critical applications, we offer tools that deliver both accuracy and resilience.

16 products

Series

Keysight
53230A

Frequency counter (counter / timer), DC to 350 MHz, 2-channel, 12 digits / s, 20 ps

Measuring range RF (MHz): 350
Measuring resolution: 12 digits/s
Number of channels: 2
Measurement resolution (gate time): 1 µS - 1000 s in 1 µs steps
Event Count (Totalize): 75.000
Input impedance: 1 MΩ parallel <25 pF or 50 Ω (switchable) / AC or DC
Interfaces: LAN, USB, GPIB
Measurement functions: Frequency, Frequency Ratio A/B, Single Period, TI, Duty, Phase, Totalize, Volts pk-pk
Min. pulse width: 20 ps
