Gossen Metrawatt M707T | Secutest ST PRO CH Device Tester, incl. IZYTRONIQ, Test Equipment for DIN EN 50678, EN 50699, EN 62353, EN 60974-4

Name: M707T | Secutest ST PRO CH Device Tester, incl. IZYTRONIQ, Test Equipment for DIN EN 50678, EN 50699, EN 62353, EN 60974-4
Brand: Gossen Metrawatt
SKU: M707T
Price: 3903.0 CHF
Availability: InStock

Manufacturer number: M707T

Delivery time upon request

CHF 3,903.00

plus VAT. CHF 4,219.14 VAT plus shipping costs

or choose one of the following options:

Request a quote Product inquiries Request education-price

Gossen Metrawatt M707T | Secutest ST PRO CH Device Tester, incl. IZYTRONIQ, Tester for DIN EN 50678, EN 50699, EN 62353, EN 60974-4.

Technical Data

Automatic test sequence:	Yes
DIN VDE0544-4 / IEC 60974-4:	Yes
DIN VDE 0701-0702:	Yes
DIN VDE 0751 / IEC62353:	Yes
Differential power:	10 - 30.00 mA
Dimensions (L x W x H) (mm):	295 x 145 x 150
EN 50678 (prepared):	Yes
EN 50699 (prepared):	Yes
Interfaces:	USB
Measured value memory:	50000
Software included:	IZYTRONIQ
Touch Display:	Yes
Weight (kg):	0

Description

M707T | Secutest ST PRO CH Device Tester, incl. IZYTRONIQ, Test Equipment for DIN EN 50678, EN 50699, EN 62353, EN 60974-4

Testing device with standard-compliant test procedures for verifying the electrical safety of equipment after repair and during periodic inspections (DGUV Regulation 3, MPBetreibV), including IZYTRONIQ data processing software.

The SECUTEST ST PRO offers all measurement and test functions for verifying the effectiveness of protective measures in electrical devices, medical devices, and welding equipment—using both predefined and programmable test sequences that comply with the test standards VDE 0701 / VDE 0702, IEC/EN 62353 (VDE 0751), and IEC/EN 60974-4 (VDE 0544-4).

The new, further-optimized measurement cycles enable even more measurements per day. And operation is so simple that tests can be performed without specialized knowledge.

Product features:

Preconfigured and user-programmable test sequences for rapid testing of electrical devices
Comprehensive data management and storage concept for automatic test sequences and individual measurements, supporting up to 50,000 data records
Report generation in HTML to a USB storage device
Create test sequences yourself using IZYTRONIQ

About the Manufacturer

Gossen Metrawatt

Gossen Metrawatt is a renowned provider of precise test and measurement technology for electrical trades, industry, and the medical sector. The portfolio includes appliance testers in accordance with VDE 0701 / VDE 0702 / VDE 0751-1, installation testers, machine testers, digital multimeters, clamp meters, insulation testers, and photovoltaic measuring instruments.
