DC Loads

In this category you will find electronic DC loads (DC sinks) for the precise simulation of loads in direct current systems. DC loads are used in a wide range of applications, for example for testing power supply units, batteries, solar cells or direct current converters. They make it possible to accurately simulate electrical energy consumers and test them under realistic conditions.

The flexible setting of current, voltage or power means that DC sinks can simulate both constant and dynamic loads. Thanks to modern technology, they offer high precision and reliability, making them indispensable for laboratories, development environments and quality control.

Whether for research, development or repair - our DC loads offer powerful functions for testing DC circuits efficiently and safely. Find the right DC load for your requirements with us.

214 products

Serie

EA Elektro-Automatik
ELR10000 2U 3kW Series

Regenerative DC loads, 1 channel, 2U, 3 kW

Output power (W): 3,000
max. voltage (V): 1
max. Power (A): 120

Price depending on choice of model

Select now

GW Instek
PEL-3041H

Electronic load, DC 800V / 17.5A / 350W, USB, RS-232, analog, GPIB opt.

AC input: 90 V - 132 V / 180 V - 250 V
Interfaces: USB/RS232/Analog Control optional: GPIB/LAN
Protective devices: OVP, OCP, OPP, OHP, UVP, REV
Measurement functions: CC, CV, CR, CP. CR and CV, CP and CV
max. voltage (V): 800
Mains feedback: No
max. Power (A): 17.5
Output power (W): 350

CHF 2,869.00

Delivery time upon request

Exclusive

Chroma
63315A

Electronic load LED simulator for 633xA series, 600V / 20A, 300W

Mains feedback: No
AC input: 100 V - 230 V
Measurement functions: 16-bit dual range I & V
max. Power (A): 20
Interfaces: RS232C optional: USB, GPIB
Output power (W): 300
max. voltage (V): 600
Protective devices: OPP, OCP, OTP, OVA

CHF 2,565.00

Delivery time upon request

Exclusive

Chroma
63218E-150-1800

DC load, 18 kW, 150 V / 1,800 A, programmable

CHF 29,386.00

Delivery time upon request

Exclusive

Chroma
63205A-150-500

DC load, 5 kW, 150 V / 500 A, programmable

Mains feedback: No
Measurement functions: V, I, Wmax OCP/OLP
max. voltage (V): 150
Output power (W): 5,000
max. Power (A): 500
Interfaces: USB optional: GPIB
Protective devices: OCP, OPP, OTP, OVA, Reverse
AC input: 100 V - 240 V

On Request

Delivery time upon request

Exclusive

Chroma
63215E-600-1050

DC load, 15 kW, 600 V / 1,050 A, programmable

CHF 31,024.00

Delivery time upon request

Exclusive

Chroma
63218E-600-1260

DC load, 18 kW, 600 V / 1,260 A, programmable

CHF 33,795.00

Delivery time upon request

Exclusive

Chroma
63212E-600-840

DC load, 12 kW, 600 V / 840 A, programmable

CHF 22,300.00

Delivery time upon request

Exclusive

Chroma
63202E-1200-80

DC load, 2 kW, 1,200 V / 80 A, programmable

CHF 8,426.00

Delivery time upon request

GW Instek
PEL-5020C-1200-800

Electronic load, DC, 1200 V / 800 A / 20 kW, PEL-5000C series

Mains feedback: No
AC input: 100 V - 240 V
max. Power (A): 800
max. voltage (V): 1
Protective devices: OPP, OCP, OVP, OTP, BMS
Measurement functions: CC, CR, CV, CP, CV and CL, CV and PL, dynamic and short circuit
Interfaces: optional: GPIB, RS-232, USB, LAN
Output power (W): 20,000

CHF 25,926.00

Delivery time upon request

Chroma
63712-600-80

Regenerative DC load 600V/80A/12kW, USB, LAN, 63700 series

max. voltage (V): 600
AC input: 200 V - 480 V
Mains feedback: Yes
Output power (W): 12,000
Protective devices: OCP, OPP, OTP, OV-Alarm
Interfaces: USB, LAN Optional: GPIB, CAN
max. Power (A): 80
Measurement functions: V, I, P

On Request

Delivery time upon request

GW Instek
PEL-3533

Electronic load, in the cabinet 150V / 1050A, 5250W, USB, RS-232

AC input: 90 V - 132 V / 180 V - 250 V
Interfaces: USB/RS232/Analog Control optional: GPIB/LAN
Protective devices: OVP, OCP, OPP, OHP, UVP, REV
Measurement functions: CC, CV, CR, CP. CR and CV, CP and CV
Mains feedback: No
max. voltage (V): 150
Output power (W): 5,250
max. Power (A): 1

CHF 14,374.00

Delivery time upon request

Series

B&K Precision
HVL Series

Electronic DC Load, High-Voltage, 600 // 800 // 1000 V, 25 // 50 // 75 // 150 // 300 A, 3 // 6 KW

max. voltage (V): 1
Output power (W): 6,000
max. Power (A): 300

Price depending on choice of model

Select now

GW Instek
PEL-5024C-150-2000

Electronic load, DC, 150 V / 2000 A / 20 kW, PEL-5000C series

Mains feedback: No
max. voltage (V): 150
AC input: 100 V - 240 V
Protective devices: OPP, OCP, OVP, OTP, BMS
Measurement functions: CC, CR, CV, CP, CV and CL, CV and PL, dynamic and short circuit
Interfaces: optional: GPIB, RS-232, USB, LAN
max. Power (A): 2
Output power (W): 24,000
