Teledyne FLIR i64 | Thermal Imaging Camera, 480 x 640 px, 38° FOV, 30 Hz, -20° C to + 450° C, 40 mK, without LTE Module, iXX Series (18455-1201)

Manufacturer number: 18455-1201

i64
i64
i64
i64
i64
i64
i64
i64
i64
i64
i64
i64
i64
i64
i64
i64
i64
i64
i64
i64
i64
i64
i64
i64
i64

On Request

or choose one of the following options:
Request a quote Product is already in cart
Product downloads Product inquiries Request education-price
Highlights Technical Data Documents / Downloads Description Scope Related Articles

FLIR i64 | app-supported thermal imaging camera, resolution 480 x 640 px, 38° FOV, 30 Hz frame rate, temperature range -20° C to + 450° C, thermal sensitivity <40 mK, without cellular module, iXX series (18455-1201).

Technical Data

Documents & Downloads

Overview
pdf | 0.35 MB
Userguide
pdf | 0.59 MB

Description

i64 | Thermal Imaging Camera, 480 x 640 px, 38° FOV, 30 Hz, -20° C to + 450° C, 40 mK, without LTE Module, iXX Series (18455-1201)

The FLIR iXX-Series combines robust, industrial-grade hardware with a modern, app-supported workflow and direct cloud connection. MSX image overlay and a thermal sensitivity < 40 mK provide clear, meaningful thermal images for fast diagnostics - from the control cabinet to the building envelope.

General features of the series:

  • App-based operation, radiometric JPEGs and direct cloud upload (Ignite/Assetlink).
  • WLAN (IEEE 802.11 a/ac/b/g/n, 2.4 & 5 GHz) in all models; LTE additionally with i35 & i65.
  • 5″ Color touch display (720 × 1280), integrated LED light and laser pointer (class 2).
  • Picture modes: MSX, thermal, picture-in-picture, digital camera; 8 MP view camera (AF), FOV 50.5° × 64.5°.
  • Thermal key data (series): 30 Hz, f/1.4, fixed focus, spectral range 7.5-13 µm, FOV (IR) 38° × 49°, minimum focus 0.5 m, NETD < 40 mK (at 30 °C).
  • Rugged: IP54, 2 m drop test, -15 °C to +50 °C operating range; 225 × 136 × 73 mm, 0.8 kg.
  • Energy: Li-Ion battery, approx. 4 hrs. runtime; charging: ~2 hrs in the charger / ~4 hrs in-cam up to 90 %.

Possible applications

  • Electrical & machine inspection: Hot connections, bearings, drives - early fault detection, less downtime.
  • Condition monitoring: Company-wide programs with asset hierarchies and cloud data management.
  • Building diagnostics & facility management: Leakage/humidity detection, HVAC checks, energy and heat loss analysis.

Model in focus: FLIR i64

The FLIR i64 is the high-resolution WLAN model in the series: with 480 × 640 pixels IR resolution for detailed thermography and an extended temperature range up to 550 °C - ideal for industry, energy supply and demanding building diagnostics.

Specifications (i64)

  • IR resolution: 480 × 640 px
  • IFOV: 1.5 mrad | FOV: 38° × 49° | Image frequency: 30 Hz
  • Optics/sensor: f/1.4, fixed focus, 7.5-13 µm, minimum focus 0.5 m
  • NETD: < 40 mK (at 30 °C)
  • Temperature ranges: -20 °C...200 °C and 10 °C...550 °C
  • Accuracy: ±2 °C or ±2 %
  • Measurement functions: Center spot, box (min./Max.), isotherms (over/under), ΔT (NFPA 70B-compliant), emissivity 0.1-1.0 (material table), atmospheric compensation, 1-touch level/span
  • Image/media: Radiometric JPEGs; MSX, thermal, PiP, digital camera modes; 8 MP view camera (AF), text annotation
  • Connectivity: WLAN (2.4/5 GHz), USB-C (data & DisplayPort); no LTE
  • Ergonomics/robustness: 5″ touch display, LED light, laser pointer; IP54, 2 m drop test

Special features of the i64

  • Very high image quality with 480 × 640 IR resolution - accurate diagnostics even at large measuring distances.
  • Extended temperature range up to 550 °C for high-temperature applications.
  • WLAN-only workflow - ideal for companies with a stable network infrastructure.
  • MSX details for quick identification of components, labels and fault locations.

Model comparison (i34 - i35 - i64 - i65)

Feature i34 i35 i64 i65
IR-Resolution 240 × 320 240 × 320 480 × 640 480 × 640
IFOV 2,9 mrad 2.9 mrad 1.5 mrad 1,5 mrad
FOV (IR) 38° × 49°
frame rate 30 Hz
Temperature ranges -20 °C...200 °C & 10 °C...450 °C -20 °C...200 °C & 10 °C...550 °C
LTE - Yes - Yes
WLAN IEEE 802.11 a/ac/b/g/n (2.4 & 5 GHz)
Digital camera 8 MP, autofocus; FOV 50.5° × 64.5°
Dimensions/Weight 225 × 136 × 73 mm - 0.8 kg

Technical highlights

  • MSX image enhancement & NETD < 40 mK for razor-sharp thermography.
  • IR resolutions up to 480 × 640 px (i64/i65) - fine details at greater measuring distances.
  • 5″ touch display, LED light and laser pointer (class 2) for convenient inspection.
  • Radiometric JPEGs and seamless cloud workflow (Ignite™/Assetlink).
  • WLAN in all models; LTE optional (i35/i65) for location-independent data uploads.
  • Measurement suite incl. spot, box, isotherms, ΔT (NFPA 70B), emissivity 0.1-1.0 and compensations.
  • Industrial grade: IP54, 2 m drop test, -15 °C...+50 °C operating range.
  • Long runtime (≈ 4 hours) and fast charging in the charger (~ 2 hours).

Lieferumfang

  • Kamera mit Akku
  • Zusatzakku
  • Ladegerät
  • USB-C-Kabel
  • Handgelenkschlaufe
  • Hardcase
  • gedruckte Dokumentation
