Spectrum Analysis / EMC

Spectrum analyzers up to 110 GHz for displaying and analyzing the frequencies contained in a signal. Ideal for development, EMC measurements and telecommunications.

240 products

Pomona
3753

Shielded miniature box, aluminium, blue enamelled, with lid

-17 % €13.28 €16.00

5 in stock. Ready to ship in 1 business day

Bundle

Rohde&Schwarz
FPL-EMI3

FPL1003 spectrum analyzer bundle, FPL series, 5 kHz to 3 GHz, 40 MHz (1304.0004P61)

-10 % €16,400.00 €18,230.00

Delivery time upon request

Series

Rohde&Schwarz
FPH series

Spectrum Rider, portable spectrum analyzers

Price depending on choice of model

Select now

Rohde&Schwarz
1321.1111P99

FPH-COM1 spectrum analyzer, handheld, Spectrum Rider FPH, "All-Inclusive", 5 kHz - 4 GHz

-15 % €11,860.00 €13,955.00

Delivery time upon request

Bundle

Rohde&Schwarz
FPL-EMI7

FPL1007 spectrum analyzer bundle, FPL series, 5 kHz to 7.5 GHz, 40 MHz (1304.0004P62)

-24 % €17,250.00 €22,985.00

Delivery time upon request

Rohde&Schwarz
FSC3

Spectrum analyzer, 9 kHz - 3 GHz, tracking generator, -141 dBm - +20 dBm, RBW 10 Hz - 3 MHz (1314.3006.13)

Sweep: linear
DANL Displayed Average Noise: -161 dBm
Resolution bandwidth: 1Hz
Filter bandwidths: 1 Hz to 3 MHz in 1/3 sequence
Dynamics: 191 dB
Interfaces: USB, LAN, audio, trigger, IF out, DC in
Detectors: max peak, min peak, auto peak, sample, RMS
max. Frequency range (GHz): 3
SSB phase noise: -95 dBc @ 500 MHz (30 kHz carrier offset)
Measurement functions: Noise marker, Modulation depth of AM-modulated signals, Power of pulsed signals in the time domain with predefined settings for GSM and EDGE mobile radio standards, Channel power measurement in a definable transmission channel with predefined settings for
min. Frequency range (KHz): 9
Amplitude range: -161 dBm to 30 dBm
Tracking-Generator: Yes
Frequency stability: 2.5 ppm

€9,920.00

Delivery time upon request

Rohde&Schwarz
FSH13

Spectrum analyzer, handheld, 9kHz - 13.6GHz preamplifier (1314.2000.13)

min. Frequency range (KHz): 9
Filter bandwidths: 1 Hz to 5 MHz in 1/3 sequence, EMI bandwidth optional
Measurement functions: Vector transmission (S12) and reflection (S22) measurement One-port cable attenuation measurement TDMA power measurement Channel power measurement Field strength measurement/measurement with isotropic antenna Measurement of the occupied bandwidth Frequenc
Detectors: max. peak, min. peak, auto peak, sample, RMS
Amplitude range: up to +30 dBm
Tracking-Generator: No
Resolution bandwidth: 1 Hz to 5 MHz
Dynamics: 185 dB
DANL Displayed Average Noise: -155 dBm
Analysis bandwidth (MHz): 20
Interfaces: USB, LAN, IF out
SSB phase noise: < -95 dBc/Hz @ 500 MHz (30 kHz carrier offset)
max. Frequency range (GHz): 13.6
Frequency stability: 1ppm
Sweep: linear, logarithmic

€18,110.00

Delivery time upon request

Series

Rohde&Schwarz
FPL1000 Series

Spectrum analyzer, 5 kHz to 7.5 GHz, 40 MHz, optional battery operation

Price depending on choice of model

Select now

Rohde&Schwarz
FSH20

Spectrum analyzer, handheld, 9 kHz - 20 GHz preamplifier (1314.2000.20)

min. Frequency range (KHz): 9
Filter bandwidths: 1 Hz to 5 MHz in 1/3 sequence, EMI bandwidth optional
Measurement functions: Vector transmission (S12) and reflection (S22) measurement One-port cable attenuation measurement TDMA power measurement Channel power measurement Field strength measurement/measurement with isotropic antenna Measurement of the occupied bandwidth Frequenc
Detectors: max. peak, min. peak, auto peak, sample, RMS
Amplitude range: up to +30 dBm
Tracking-Generator: No
Resolution bandwidth: 1 Hz to 5 MHz
Dynamics: 185 dB
DANL Displayed Average Noise: -155 dBm
Analysis bandwidth (MHz): 20
Interfaces: USB, LAN, IF out
SSB phase noise: < -95 dBc/Hz @ 500 MHz (30 kHz carrier offset)
Frequency stability: 1ppm
Sweep: linear, logarithmic
max. Frequency range (GHz): 20

€22,930.00

Delivery time upon request

Rohde&Schwarz
FSH8

Spectrum analyzer, handheld, 100 kHz - 8 GHz preamplifier, tracking generator, VSWR bridge (1309.6000.28)

Tracking-Generator: Yes
Filter bandwidths: 1 Hz to 5 MHz in 1/3 sequence, EMI bandwidth optional
Measurement functions: Vector transmission (S12) and reflection (S22) measurement One-port cable attenuation measurement TDMA power measurement Channel power measurement Field strength measurement/measurement with isotropic antenna Measurement of the occupied bandwidth Frequenc
Detectors: max. peak, min. peak, auto peak, sample, RMS
Amplitude range: up to +30 dBm
Resolution bandwidth: 1 Hz to 5 MHz
Dynamics: 185 dB
DANL Displayed Average Noise: -155 dBm
Analysis bandwidth (MHz): 20
Interfaces: USB, LAN, IF out
SSB phase noise: < -95 dBc/Hz @ 500 MHz (30 kHz carrier offset)
Frequency stability: 1ppm
Sweep: linear, logarithmic
max. Frequency range (GHz): 8
min. Frequency range (KHz): 100

€20,750.00

Delivery time upon request

Rohde&Schwarz
FSH13

Spectrum analyzer, handheld, 9kHz - 13.6GHz preamplifier, tracking generator, VSWR measuring bridge (1314.2000.23)

min. Frequency range (KHz): 9
Tracking-Generator: Yes
Filter bandwidths: 1 Hz to 5 MHz in 1/3 sequence, EMI bandwidth optional
Measurement functions: Vector transmission (S12) and reflection (S22) measurement One-port cable attenuation measurement TDMA power measurement Channel power measurement Field strength measurement/measurement with isotropic antenna Measurement of the occupied bandwidth Frequenc
Detectors: max. peak, min. peak, auto peak, sample, RMS
Amplitude range: up to +30 dBm
Resolution bandwidth: 1 Hz to 5 MHz
Dynamics: 185 dB
DANL Displayed Average Noise: -155 dBm
Analysis bandwidth (MHz): 20
Interfaces: USB, LAN, IF out
SSB phase noise: < -95 dBc/Hz @ 500 MHz (30 kHz carrier offset)
max. Frequency range (GHz): 13.6
Frequency stability: 1ppm
Sweep: linear, logarithmic

€21,830.00

Delivery time upon request

Rohde&Schwarz
FSC6

Spectrum analyzer, 9 kHz - 6 GHz, tracking generator, -141 dBm - +20 dBm, RBW 10 Hz - 3 MHz (1314.3006.16)

Sweep: linear
DANL Displayed Average Noise: -161 dBm
Resolution bandwidth: 1Hz
Filter bandwidths: 1 Hz to 3 MHz in 1/3 sequence
Dynamics: 191 dB
Interfaces: USB, LAN, audio, trigger, IF out, DC in
Detectors: max peak, min peak, auto peak, sample, RMS
SSB phase noise: -95 dBc @ 500 MHz (30 kHz carrier offset)
Measurement functions: Noise marker, Modulation depth of AM-modulated signals, Power of pulsed signals in the time domain with predefined settings for GSM and EDGE mobile radio standards, Channel power measurement in a definable transmission channel with predefined settings for
min. Frequency range (KHz): 9
Amplitude range: -161 dBm to 30 dBm
Tracking-Generator: Yes
Frequency stability: 2.5 ppm
max. Frequency range (GHz): 6

€12,400.00

Delivery time upon request

Rohde&Schwarz
FSH20

Spectrum analyzer, handheld, 9 kHz - 20 GHz preamplifier, tracking generator, VSWR bridge (1314.2000.30)

min. Frequency range (KHz): 9
Tracking-Generator: Yes
Filter bandwidths: 1 Hz to 5 MHz in 1/3 sequence, EMI bandwidth optional
Measurement functions: Vector transmission (S12) and reflection (S22) measurement One-port cable attenuation measurement TDMA power measurement Channel power measurement Field strength measurement/measurement with isotropic antenna Measurement of the occupied bandwidth Frequenc
Detectors: max. peak, min. peak, auto peak, sample, RMS
Amplitude range: up to +30 dBm
Resolution bandwidth: 1 Hz to 5 MHz
Dynamics: 185 dB
DANL Displayed Average Noise: -155 dBm
Analysis bandwidth (MHz): 20
Interfaces: USB, LAN, IF out
SSB phase noise: < -95 dBc/Hz @ 500 MHz (30 kHz carrier offset)
Frequency stability: 1ppm
Sweep: linear, logarithmic
max. Frequency range (GHz): 20

€26,120.00

Delivery time upon request

Rohde&Schwarz
FSC3

Spectrum analyzer, 9 kHz - 3 GHz, -141 dBm - +20 dBm, RBW 10 Hz - 3 MHz (1314.3006.03)

Sweep: linear
DANL Displayed Average Noise: -161 dBm
Resolution bandwidth: 1Hz
Filter bandwidths: 1 Hz to 3 MHz in 1/3 sequence
Dynamics: 191 dB
Interfaces: USB, LAN, audio, trigger, IF out, DC in
Detectors: max peak, min peak, auto peak, sample, RMS
max. Frequency range (GHz): 3
SSB phase noise: -95 dBc @ 500 MHz (30 kHz carrier offset)
min. Frequency range (KHz): 9
Amplitude range: -161 dBm to 30 dBm
Frequency stability: 2.5 ppm
Tracking-Generator: No
Measurement functions: Noise marker, Modulation depth of AM-modulated signals, Power of pulsed signals in the time domain with predefined settings for GSM and EDGE mobile radio standards, Channel power measurement in a definable transmission channel with predefined settings for

€8,010.00

Delivery time upon request

Exclusive

YIC Technologies
EMP-DBT-M

EMProbe basic device, main arm scanning range 250 mm and 180 °, 3-D precision scan for near field probes

min. Step size (mm): 0.2
Bandwidth (GHz): 14

On Request

Delivery time upon request

Rohde&Schwarz
HZ-17

Near-field probe set, for H-field, 30 MHz - 3 GHz (1339.4141.02)

€1,200.00

Delivery time upon request

Rohde&Schwarz
FSH8

Spectrum analyzer, handheld, 9 kHz - 8 GHz, preamplifier, tracking generator (1309.6000.18)

min. Frequency range (KHz): 9
Tracking-Generator: Yes
Filter bandwidths: 1 Hz to 5 MHz in 1/3 sequence, EMI bandwidth optional
Measurement functions: Vector transmission (S12) and reflection (S22) measurement One-port cable attenuation measurement TDMA power measurement Channel power measurement Field strength measurement/measurement with isotropic antenna Measurement of the occupied bandwidth Frequenc
Detectors: max. peak, min. peak, auto peak, sample, RMS
Amplitude range: up to +30 dBm
Resolution bandwidth: 1 Hz to 5 MHz
Dynamics: 185 dB
DANL Displayed Average Noise: -155 dBm
Analysis bandwidth (MHz): 20
Interfaces: USB, LAN, IF out
SSB phase noise: < -95 dBc/Hz @ 500 MHz (30 kHz carrier offset)
Frequency stability: 1ppm
Sweep: linear, logarithmic
max. Frequency range (GHz): 8

€14,970.00

Delivery time upon request

Rohde&Schwarz
FSC6

Spectrum analyzer, 9 kHz - 6 GHz, -141 dBm - +20 dBm, RBW 10 Hz - 3 MHz (1314.3006.06)

Sweep: linear
DANL Displayed Average Noise: -161 dBm
Resolution bandwidth: 1Hz
Filter bandwidths: 1 Hz to 3 MHz in 1/3 sequence
Dynamics: 191 dB
Interfaces: USB, LAN, audio, trigger, IF out, DC in
Detectors: max peak, min peak, auto peak, sample, RMS
SSB phase noise: -95 dBc @ 500 MHz (30 kHz carrier offset)
min. Frequency range (KHz): 9
Amplitude range: -161 dBm to 30 dBm
Frequency stability: 2.5 ppm
Tracking-Generator: No
max. Frequency range (GHz): 6
Measurement functions: Noise marker, Modulation depth of AM-modulated signals, Power of pulsed signals in the time domain with predefined settings for GSM and EDGE mobile radio standards, Channel power measurement in a definable transmission channel with predefined settings for

€10,350.00

Delivery time upon request

Rohde&Schwarz
FSH4

Spectrum analyzer, handheld, 9 kHz - 3.6 GHz preamplifier, tracking generator (1309.6000.14)

min. Frequency range (KHz): 9
Tracking-Generator: Yes
Filter bandwidths: 1 Hz to 5 MHz in 1/3 sequence, EMI bandwidth optional
Measurement functions: Vector transmission (S12) and reflection (S22) measurement One-port cable attenuation measurement TDMA power measurement Channel power measurement Field strength measurement/measurement with isotropic antenna Measurement of the occupied bandwidth Frequenc
Detectors: max. peak, min. peak, auto peak, sample, RMS
Amplitude range: up to +30 dBm
Resolution bandwidth: 1 Hz to 5 MHz
Dynamics: 185 dB
DANL Displayed Average Noise: -155 dBm
Analysis bandwidth (MHz): 20
Interfaces: USB, LAN, IF out
SSB phase noise: < -95 dBc/Hz @ 500 MHz (30 kHz carrier offset)
Frequency stability: 1ppm
Sweep: linear, logarithmic
max. Frequency range (GHz): 3.6

€12,320.00

Delivery time upon request

Exclusive

YIC Technologies
EMS8000

EMC near-field scanner board for locating EMC problems; 150kHz to 8GHz

Scanning area (X,Y,Z) (mm): 316 x 218
Bandwidth (GHz): 8

On Request

Delivery time upon request

Rohde&Schwarz
FSH8

Spectrum analyzer, handheld, 9 kHz - 8 GHz, preamplifier (1309.6000.08)

min. Frequency range (KHz): 9
Filter bandwidths: 1 Hz to 5 MHz in 1/3 sequence, EMI bandwidth optional
Measurement functions: Vector transmission (S12) and reflection (S22) measurement One-port cable attenuation measurement TDMA power measurement Channel power measurement Field strength measurement/measurement with isotropic antenna Measurement of the occupied bandwidth Frequenc
Detectors: max. peak, min. peak, auto peak, sample, RMS
Amplitude range: up to +30 dBm
Tracking-Generator: No
Resolution bandwidth: 1 Hz to 5 MHz
Dynamics: 185 dB
DANL Displayed Average Noise: -155 dBm
Analysis bandwidth (MHz): 20
Interfaces: USB, LAN, IF out
SSB phase noise: < -95 dBc/Hz @ 500 MHz (30 kHz carrier offset)
Frequency stability: 1ppm
Sweep: linear, logarithmic
max. Frequency range (GHz): 8

€13,160.00

Delivery time upon request

Rohde&Schwarz
FPC1500

Spectrum analyzer, 5 kHz to 1/2 or 3 GHz, integr. Track gen., Opt. Network analysis (1328.6660.03)

Sweep: linear
Resolution bandwidth: 1Hz
Dynamics: 191 dB
max. Frequency range (GHz): 3
Frequency stability: 2.5 ppm
Tracking-Generator: No
Amplitude range: -158 dBm to 33 dBm
Analysis bandwidth (MHz): 2
Detectors: max. peak, min. peak, auto peak, sample, RMS, with receiver option max. peak, average, RMS, quasi-peak
SSB phase noise: -88 dBc @ 500 MHz (30 kHz carrier offset)
Interfaces: USB, LAN
Measurement functions: FPC-K7 modulation analysis, FPC-K43 receiver mode, FPC-K55 advanced measurements (spectrogram, channel power, occupied bandwidth, intermodulation products, harmonic distortion, TDMA power, AM modulation depth).
Filter bandwidths: 1 Hz to 3 MHz in 1/3 sequence, CISPR 200 Hz, 9 kHz, 120 kHz, 1 MHz optional
DANL Displayed Average Noise: approx. -158 dBm
min. Frequency range (KHz): 5

€2,900.00

Delivery time upon request

Rohde&Schwarz
FSH4

Spectrum analyzer, handheld, 100kHz - 3.6GHz preamplifier, tracking generator, VSWR bridge (1309.6000.24)

Tracking-Generator: Yes
Filter bandwidths: 1 Hz to 5 MHz in 1/3 sequence, EMI bandwidth optional
Measurement functions: Vector transmission (S12) and reflection (S22) measurement One-port cable attenuation measurement TDMA power measurement Channel power measurement Field strength measurement/measurement with isotropic antenna Measurement of the occupied bandwidth Frequenc
Detectors: max. peak, min. peak, auto peak, sample, RMS
Amplitude range: up to +30 dBm
Resolution bandwidth: 1 Hz to 5 MHz
Dynamics: 185 dB
DANL Displayed Average Noise: -155 dBm
Analysis bandwidth (MHz): 20
Interfaces: USB, LAN, IF out
SSB phase noise: < -95 dBc/Hz @ 500 MHz (30 kHz carrier offset)
Frequency stability: 1ppm
Sweep: linear, logarithmic
min. Frequency range (KHz): 100
max. Frequency range (GHz): 3.6

€15,270.00

Delivery time upon request

Rohde&Schwarz
FSH4

Spectrum analyzer, handheld, 9 kHz - 3.6 GHz preamplifier (1309.6000.04)

min. Frequency range (KHz): 9
Filter bandwidths: 1 Hz to 5 MHz in 1/3 sequence, EMI bandwidth optional
Measurement functions: Vector transmission (S12) and reflection (S22) measurement One-port cable attenuation measurement TDMA power measurement Channel power measurement Field strength measurement/measurement with isotropic antenna Measurement of the occupied bandwidth Frequenc
Detectors: max. peak, min. peak, auto peak, sample, RMS
Amplitude range: up to +30 dBm
Tracking-Generator: No
Resolution bandwidth: 1 Hz to 5 MHz
Dynamics: 185 dB
DANL Displayed Average Noise: -155 dBm
Analysis bandwidth (MHz): 20
Interfaces: USB, LAN, IF out
SSB phase noise: < -95 dBc/Hz @ 500 MHz (30 kHz carrier offset)
Frequency stability: 1ppm
Sweep: linear, logarithmic
max. Frequency range (GHz): 3.6

€10,110.00

Delivery time upon request
