CompactRIO Modules

NI (National Instruments) CompactRIO I/O modules with signal conditioning enable connection to a wide range of sensors and bus systems and support measurement of temperature, voltage, impedance, and audio frequencies, among others.

234 products

NI
779136-02

NI 9421, current sinking digital input module with 8 channels, 24 V, 100 µs, protective coating

Logic level of the digital I/O: 24 V, 12 V
Number of bidirectional digital channels: 0
With case: Yes
Number of digital inputs: 8
Logic level and range: 24 V, 12 V
Number of digital outputs: 0

€505.00

Delivery time upon request

NI
779011-01

NI 9215, analog input module with 4 channels, 100 kS / s per channel, 16 bit, +/- 10 V, screw terminals

With case: Yes
Voltage measuring range of the analogue input (V): -10 V bis 10 V
Samplerate: 100 kS/s per channel
Measurements per second/sampling rate (MS/s): 0.1
Max. Number of differential analogue input channels: 4

€1,090.00

6 in stock. Ready to ship in 1 business day

NI
785189-01

NI 9226 spring terminals, analog input module, 8 channels for Pt1000-RTD, 24 bit, 50 S / s per channel

With case: Yes
Samplerate: 400 S/s
Max. Number of differential analogue input channels: 8
Measurements per second/sampling rate (MS/s): 0

€1,830.00

Delivery time upon request

NI
785045-01

NI 9476 C series digital output module, spring clip, 32 channels, 24 V, 500 microseconds, sourcing

Logic level of the digital I/O: 24 V, 12 V
Number of bidirectional digital channels: 0
With case: Yes
Logic level and range: 24 V, 12 V, 6.0V - 36.0V
Number of digital outputs: 32
Number of digital inputs: 0

€710.00

11 in stock. Ready to ship in 1 business day

NI
783362-01

NI 9218, universal analog input module, 2 channels, 51.2 kS / s per channel, 24 bit, D-Sub connection

With case: Yes
Measurements per second/sampling rate (MS/s): 0.051
Samplerate: 51.2 kS/s per channel
Max. Number of differential analogue input channels: 2

€1,920.00

Delivery time upon request

NI
780874-01

NI 9229E, analog input module, 4 channels, channel isolation, 50 kS / s per channel, 24 bit, ± 60 V, ONLY BOARD

Max. Number of differential analogue input channels: 4
Voltage measuring range of the analogue input (V): -60 V bis 60 V
Measurements per second/sampling rate (MS/s): 0.05
With case: No
Samplerate: 50 kS/s per channel

€2,570.00

Delivery time upon request

NI
780927-01

NI 9264, analog output module, 16 channels, 25 kS / s, 16 bit, ± 10 V (D-Sub connection)

With case: Yes
Max. Update rate (MS/s): 0.025
Samplerate: 25 kS/s per channel
Measurements per second/sampling rate (MS/s): 0.025
Number of analogue output channels: 16
Max. Output current (mA): 4

€1,930.00

3 in stock. Ready to ship in 1 business day

NI
781580-01

NI 9236E, quarter bridge input module, 350 ohms, 8 channels, 24 bit, card only

Max. Number of differential analogue input channels: 8
With case: No
Measurements per second/sampling rate (MS/s): 0.01
Samplerate: 10 kS/s per channel
Voltage measuring range of the analogue input (V): -29.4 mV/V bis 29.4 mV/V

€2,870.00

Delivery time upon request

NI
783589-01

NI 9247, C series analog input module, 3 channels, 50 kS / s per channel, 24 bit, 50 A

With case: Yes
Measurements per second/sampling rate (MS/s): 0.05
Samplerate: 50 kS/s per channel
Max. Number of differential analogue input channels: 3

€2,300.00

Delivery time upon request

NI
784717-02

NI 9476, digital output module with DSUB, protective coating, for Joy Global

Number of bidirectional digital channels: 0
With case: Yes
Logic level and range: 24 V, 12 V
Number of digital outputs: 32
Number of digital inputs: 0
Logic level of the digital I/O: 12 V, 24 V

On Request

1 in stock. Ready to ship in 1 business day

NI
779785-02

NI 9229, analog input module with protective coating, 4 channels, ± 60 V, 50 kS / s per channel, 24 bit, channel-by-channel isolation

With case: Yes
Max. Number of differential analogue input channels: 4
Voltage measuring range of the analogue input (V): -60 V bis 60 V
Measurements per second/sampling rate (MS/s): 0.05
Samplerate: 50 kS/s per channel

€3,040.00

Delivery time upon request

NI
779139-01

NI 9425, current sinking digital input module, 32 channels, 24 V, 7 µs

Number of bidirectional digital channels: 0
With case: Yes
Logic level and range: 24 V, 12 V
Number of digital outputs: 0
Logic level of the digital I/O: 12 V, 24 V
Number of digital inputs: 32

€675.00

5 in stock. Ready to ship in 1 business day

NI
779891-02

NI 9870, 4-port RS232 serial module (module only)

With case: Yes
Communication protocol: Serial, CANopen

€1,150.00

1 in stock. Ready to ship in 1 business day

NI
782000-01

NI 9232, IEPE analog input module, 3 channels, 102.4 kS / s, 24 bit, ± 30 V.

With case: Yes
Max. Number of differential analogue input channels: 3
Samplerate: 102.4 kS/s per channel
Measurements per second/sampling rate (MS/s): 0.102
Voltage measuring range of the analogue input (V): -30 V bis 30 V

€3,140.00

Delivery time upon request

NI
784397-01

NI 9232 BNC, 3 channels, +/- 30 V, 102.4 kS / s / channel, 24-bit, IEPE-AI-C module

With case: Yes
Max. Number of differential analogue input channels: 3
Samplerate: 102.4 kS/s per channel
Measurements per second/sampling rate (MS/s): 0.102
Voltage measuring range of the analogue input (V): -30 V bis 30 V

€3,140.00

Delivery time upon request

NI
785965-01

sbRIO-9866, LIN interface module of the C series with 1 connection, only circuit board

With case: Yes

€1,210.00

Delivery time upon request

NI
781099-02

NI 9227 CC, C-Series power input module, with protective coating

With case: Yes
Max. Number of differential analogue input channels: 4
Measurements per second/sampling rate (MS/s): 0.05
Samplerate: 50 kS/s per channel

€2,570.00

Delivery time upon request

NI
782615-01

NI 9220, analog input module with simultaneous sampling, 16 channels, 100 kS / s, 16 bit, +/- 10 V, D-Sub connection

With case: Yes
Voltage measuring range of the analogue input (V): -10 V bis 10 V
Samplerate: 100 kS/s per channel
Measurements per second/sampling rate (MS/s): 0.1
Max. Number of differential analogue input channels: 16

€3,230.00

Delivery time upon request

NI
781120-01

NI 9269E, voltage output module, 4 channels, channel isolation, ± 10 V, ONLY BOARD

With case: No
Number of analogue output channels: 4
Max. Update rate (MS/s): 0.1
Max. Output current (mA): 10

€1,540.00

Delivery time upon request

NI
785190-02

Voltage output module of the C series NI-9264 with clamp connection, protective coating, 16 channels, 24 bit, ± 10 V, 25 kS / s per channel

With case: Yes
Max. Update rate (MS/s): 0.025
Samplerate: 25 kS/s per channel
Measurements per second/sampling rate (MS/s): 0.025
Number of analogue output channels: 16
Max. Output current (mA): 4

€2,260.00

Delivery time upon request

NI
789127-01

NI 9227 Snap-in, current input module, 4 channels, channel-by-channel isolation, 5 A, 50 kS/s, 24 bit

€1,390.00

Delivery time upon request

NI
779781-02

NI 9219, universal analog input module, 4 channels, individually isolated, protective coating

With case: Yes
Max. Number of differential analogue input channels: 4
Measurements per second/sampling rate (MS/s): 0
Voltage measuring range of the analogue input (V): -125 V bis 125 V, -60 V bis 60 V, -4 V bis 4 V, -15 V bis 15 V, -1 V bis 1 V
Samplerate: 100 S/s per channel
