Pico PP815 | Data logger, USB, 3 channel, CM3, without current probe

Name: PP815 | Data logger, USB, 3 channel, CM3, without current probe
Brand: Pico
SKU: PP815
Price: 449.0 CHF
Availability: OutOfStock

Manufacturer number: PP815

Delivery time upon request

CHF 449.00

plus VAT. CHF 485.37 VAT plus shipping costs

You would like to request an offer? Please add items to the shopping cart and request an offer there.

Request educational price

Pico PP815 | PicoLog CM3 USB / Ethernet data logger.

Channels: 3
Range (voltage input): 0 to 1 V AC eff.
Accuracy (voltage input): ± 1% (up to 200 mV) ± 2.5% (up to 1 V)
Overload protection: ± 30 V DC
Voltage input: 1 V rms, 20 Hz to 1 kHz
Resolution: 24 bit ADC
Sampling rate: <1 second per conversion
Inputs 4 mm sockets
PC connection: USB or Ethernet
Dimensions 184 x 135 x 36 mm
Warranty: 5 years

Features and highlights TA138 current probe:

Range (1 mV / A) 0.1 to 200 A AC eff.
Accuracy ± 2%, ± 0.5 A
Output voltage 1 mV / A
Maximum output impedance 1 kΩ
Maximum conductor cross section 16 mm
Output connectors 4mm banana plug
Size in mm (W x L x D) 111 x 50 x 33 mm
Weight 129 g

Manufacturer-independent

Wide variety of brands from dataTec.

To the brands

Large product portfolio

All the highlights of dataTec Switzerland at a glance.

Download here

Demonstration & Consulting

Sales and technical support close to you.

Start request

Technical Data

Accuracy voltage measurement AC:	< 200 mV RMS ±1% < 1 V RMS ±2.5%
Article number:	PP815
Connection types:	analoge Kanäle
Dimensions (L x W x H) (mm):	184 x 135 x 36
Display:	ohne
Interfaces:	USB
Measured value memory:	1Ks/s
Model:	PicoLog CM3
Number of channels:	3
Resolution (bit):	24
Special features:	USB-Datenlogger
Voltage measuring range AC:	0 bis 1V
Warranty (years):	5
Weight (kg):	0.5

Detaildescription

PP815 | Data logger, USB, 3 channel, CM3, without current probe

The PicoLog CM3 USB / Ethernet data recorder for mains power is a compact and easy-to-use device for measuring the power consumption of buildings and machines. With three channels, high accuracy and low noise, it is ideal for recording data from single and three-phase AC power supplies.
The USB and Ethernet interfaces enable the data recording device to be used as a pure USB device, as a device with USB power supply and Ethernet interface or as a Power-over-Ethernet (PoE) device. The PicoLog CM3 can be operated in a LAN or over the Internet via the Ethernet interface.

Lieferumfang

Range (1 mV / A) 0.1 to 200 A AC eff.
Accuracy ± 2%, ± 0.5 A
Output voltage 1 mV / A
Maximum output impedance 1 kΩ
Maximum conductor cross section 16 mm
Output connectors 4mm banana plug
Size in mm (W x L x D) 111 x 50 x 33 mm
Weight 129 g

Accessoires (1 product )

Pico TA138 200 A AC current clamp

Delivery time upon request

CHF 70.00

Alternate products (1 product )

Pico PP803

Data logger, USB, 3 channel CM3, with 3x TA138 AC current clamps

Delivery time upon request

CHF 609.00

Recommendations (2 products )

Pico PP547

Data logger, USB, 16 channel 1216, with terminal board

Delivery time upon request

CHF 278.00

Pico PP682

Data logger, USB, 4 channels, PT-104, 4 pol. Mini-DIN sockets for PT100 and PT1000

Delivery time upon request

CHF 706.00

About the Manufacturer

Pico

Pico Technology, the leader in USB oscilloscope technology, offers innovative, high-quality and affordable alternatives to traditional benchtop meters. The wide range of PC-based digital oscilloscopes offers a full range of functions. The Pico data loggers are ideal for measuring and storing temperature, humidity, current and voltage.
