GW Instek PPE-3323 | Power supply unit, DC, 3 channel, linear 32V / 3A, -32V / 3A, 5V / 3A, RS-232

Manufacturer number: PPE-3323

PPE-3323
PPE-3323
PPE-3323
PPE-3323
Delivery time upon request

CHF 612.00

plus VAT. CHF 661.57 VAT plus shipping costs

or choose one of the following options:
Request a quote Product is already in cart
Product inquiries Request education-price
Highlights Technical Data Description Related Articles

GW Instek PPE-3323 | Programmable, linear 3-channel DC power supply, 32 V / 3 A, -32 V / 3 A, 5 V / 3 A, 207 W.

  • Channels: 3 independent channels
  • Output power: 207 W.
  • Output voltage: 0… 32 V, 0… -32 V, 5 V fixed
  • Output current: 0… 3 A, 0… -3 A, 3 A fixed
  • Resolution voltage: 10 mV
  • Resolution current: 1 mA
  • Program accuracy voltage: ≤ 0.05% + 25 mV
  • Program accuracy current: ≤ 0.2% + 10mA
  • Display: 2 x 3 ¾ digit LED display
  • Ripple and noise voltage:
    Ripple 1 mV RMS / 3 mV P-P
    Noise 2 mV RMS / 30 mV P-P
  • Residual ripple and noise current: <3 mA RMS (<5 mA RMS rating current> 3.5 A)
  • Memory: 50 storable settings
  • RS-232 interface
  • Weight: 10 kg, dimensions: W 255 mm x H 145 mm x D 346 mm
  • Power supply: AC 100 V / 120 V / 220 V / 240 V ± 10%, 50/60 Hz

Technical Data

Description

PPE-3323 | Power supply unit, DC, 3 channel, linear 32V / 3A, -32V / 3A, 5V / 3A, RS-232

The GW Instek PPE-3323 is a programmable, linear 3-channel DC power supply with an output power of 207 W. When connected in series you get a supply of 64 V / 3 A; connected in parallel from 32 V / 6 A.

The power supply has very low ripple and noise values and gives you precise current and voltage values. This makes it ideal for bench-top and laboratory applications.

The power source is characterized by its simple, intuitive usability. With the high resolution of 10 mV / 1 mA, the PPE 3323 can be optimally adjusted to your specific requirements. 50 different settings can be saved and thus quickly and easily called up again.

Two 3 ¾ digit LED displays show you all settings and values clearly and at first glance. The GW Instek PPE-3323 is equipped with software-controlled protection mechanisms, such as over voltage protection (OVP) and over current protection (OCP). The DC source has an RS-232 interface, which you can use to connect a PC, for example. With the free remote control software, all settings can be conveniently made on the Windows computer and transferred to the power supply.
