Elettrotest TPS / T / 60K | Power supply unit, AC, 1/3-phase 300V / 240A / 60kVA / 40 - 80 Hz isolated

Name: TPS / T / 60K | Power supply unit, AC, 1/3-phase 300V / 240A / 60kVA / 40 - 80 Hz isolated
Brand: Elettrotest
SKU: TPS/T/60K
Availability: InStock

Manufacturer number: TPS/T/60K

Delivery time upon request

On Request

or choose one of the following options:

Request a quote Product inquiries Request education-price Share

Elettrotest TPS / T / 60K | Power supply unit, AC, 1/3-phase 300V / 480 / 60kVA / output frequency 10 Hz to 80 Hz in remote control mode.

Output: 1- or 3-phase
Output power: 60 kVA
Output frequency: 10 Hz to 80 Hz (40 Hz to 80 Hz via keyboard)
Output voltage 0 to 300 volts AC
Ranges: 150/300 V
Accuracy: <0.5%
Stability: <0.1%
Control: RS232, LabView driver (alternatively SCPI protocol available)
Optional (via adapter): LAN, GPIB, RS485, PLC interface
Dimensions: W1200 x H1.800 x D800 mm
Weight: 960 kg
Connection: 400 V AC, 3 PH

Technical Data

AC input:	400 V ±10 % 3P without N
AC output:	1P / 3P
Article number:	99110540
Dimensions (L x W x H) (mm):	800 x 1200 x 1800
Frequency range:	40 Hz - 80 Hz
Grid simulation:	No
Interfaces:	RS-232 Optional: LAN, RS-485
Mains feedback:	No
Model:	TPS/T/60K
Output power (W):	72,000
PLD Testfunction:	No
Protective devices:	OVP, UVP, OTP
Weight (kg):	960
max. Power (A):	80
max. voltage (V):	300

Description

TPS / T / 60K | Power supply unit, AC, 1/3-phase 300V / 240A / 60kVA / 40 - 80 Hz isolated

High-performance AC power supply series (AC source) designed for industrial test and inspection use and the ideal test source for products with AC motors, such as household appliances, motor tools etc. and / or for product tests of export devices by simply carrying out the respective frequency and output voltage .

The devices are power-limited, the output is short-circuit proof and designed for continuous power, thermal overload protection is standard. The output voltage and frequency are specified via the membrane keyboard on the front or via the built-in RS232 interface.
